2.3 Error IDs and Remedial Procedures
Error ID Item Description
0101000 Table X Origin Zeroing opn. was incompleted, within specified time.
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Wipe off dirt on the sensor and zero Table X again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, zero Table X.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
0102000 Table X Origin Detect lost pulse error.
(Cause 1) The motor is overloaded and has a loss of synchronism.
(Remedy 1) Check for any obstacle around the table X axis and then perform the
zeroing operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0103000 Table X Limit (+) Limit error has been detected.
0104000 Table X Limit (-) Limit error has been detected.
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Wipe off dirt on the sensor and zero Table X again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, zero Table X.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 8 AFU01ETRP
Error ID Item Description
0105000 Table X Limit Driver alarm signal was detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0108000 Table X Limit Driver Over-Heat
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0109000 Table X Limit Operatuon was incompleted, within specified time.
(Cause 1) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
0110000 Table X Interlock Table-Z Axis is not at safety area.
(Cause 1) The table Z axis interlock sensor (BPH055) is defective.
(Cause 2) The operation timing is shifted from the normal one.
(Remedy 1) Check how the sensor is working in “Device Check” window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 9 AFU01ETRP
Error ID Item Description
0111000 Table X Interlock Table-Z Axis is not at origin.
(Cause 1) The table Z-axis interlock sensor (BPH171) is defective.
(Cause 2) The operation timing is shifted from the normal one.
(Remedy 1) Check how the sensor is working in “Device Check” window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
0112000 Table X Interlock P.C.B. stopper was down.
(Cause 1) The table X axis was activated after the P.C.B. stopper had moved down.
(Cause 2) The P.C.B. stopper upper limit (BPS070) is defective.
(Remedy 1) Move up the P.C.B. stopper and re-start the operation.
(Remedy 2) Adjust the sensor position.
If this operation does not reset the machine to its normal condition, it is
required to replace the sensor with a new one. Contact our service per-
sonnel for details.
0113000 Table X interlock P.C.B. warpage protection was down.
(Cause 1) The table X axis was activated after the P.C.B. warpage protection had moved
down.
(Remedy 1) Move up the P.C.B. warpage protection and re-start the operation.
0114000 Table X Interlock Table-
θθ
θθ
θ Axis is not at origin.
(Cause 1) The operating timing may be shifted from the normal one.
(Remedy 1) Power up the machine again and then perform the zeroing operation.
