Error ID Item Description
2102000 Operator's Error P.C.B. was took on inp. conveyor.
(Cause 1) Although a manual operation cannot be implemented with a P.C.B. on the
input conveyor, such an operation was performed with a P.C.B.
(Remedy 1) Remove the P.C.B. on the input conveyor and re-start the operation.
2103000 Operator's Error P.C.B. removed from input conveyor.
(Cause 1) Although a manual operation cannot be implemented without a P.C.B. on
the input conveyor, such an operation was performed without a P.C.B.
(Remedy 1) Place a P.C.B. on an area of the input conveyor where the sensor reacts.
2105000 Operator's Error Vacuum plate was not found.
(Cause 1) The automatic or the manual operation was performed without any pattern
program specified as a current one.
(Remedy 1) Perform a program change operation.
2106000 Operator's Error P.C.B. was took on table.
(Cause 1) Although a manual operation cannot be implemented with a P.C.B. on the
table, such an operation was performed with a P.C.B.
(Remedy 1) Remove the P.C.B. on the table and re-start the operation.
Click the table section (illustrated) in the "AUTO OPN." window to re-
move the P.C.B. from the memory of the machine whenever necessary.
2107000 Operator's Error P.C.B. removed from table.
(Cause 1) Although a manual operation cannot be implemented without a P.C.B. on
the table, such an operation was performed without a P.C.B.
(Remedy 1) Place a P.C.B. on the table and re-start the operation.
Click the table section (illustrated) in the "AUTO OPN." window to set the
P.C.B. in the memory of the machine whenever necessary.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 69 AFU01ETRP
Error ID Item Description
2108000 Operator's Error P.C.B. was took on output conveyor.
(Cause 1) Although a manual operation cannot be implemented with a P.C.B. on the
output conveyor, such an operation was performed with a P.C.B.
(Remedy 1) Remove the P.C.B. on the output conveyor and re-start the operation.
2109000 Operator's Error P.C.B. removed from output conveyor.
(Cause 1) Although a manual operation cannot be implemented without a P.C.B. on
the output conveyor, such an operation was performed without a P.C.B.
(Remedy 1) Place a P.C.B. on an area of the output conveyor where the sensor re-
acts.
2113000 Operator's Error Vacuum cleaning can not use in vacuum plate chuck on.
(Cause 1) The operation timing is shifted from the normal one.
(Cause 2) A cleaning suction operation was performed during the vacuum cleaning
(chuck suction). (during the manual operation)
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 2) Cancel the chuck suction operation through manual operation and re-
start the operation.
2114000 Operator's Error Vacuum plate can not use at vacuum cleaning on.
(Cause 1) The operation timing is shifted from the normal one.
(Cause 2) A chuck suction operation was performed during the vacuum cleaning (chuck
suction). (during the manual operation)
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 2) Cancel the cleaning suction operation through manual operation and re-
start the operation.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 70 AFU01ETRP
Error ID Item Description
2115000 Operator's Error Input conveyor width was out of specified range.
2116000 Operator's Error Table chute width was out of specified range.
2117000 Operator's Error Output conveyor width was out of specified range.
(Cause 1) The P.C.B. dimension (Y) in the current pattern program differs extremely
from the input conveyor width.
(Remedy 1) Open the "ALL PROD. CHG." window and change the conveyor width.
2118000 Operator's Error Screen recog. was not finished.
(Cause 1) An operation was performed to check the results of the screen recognition
although no screen recognition operation is performed yet.
(Remedy 1) Perform the screen recognition.
2121000 Operator's Error Not printed P.C.B. exists on the table.
(Cause 1) An unprinted P.C.B. was discharged during the automatic operation after an
error was canceled.
(Remedy 1) Remove the unprinted P.C.B. on the table and re-start the operation.
Click the table section (illustrated) in the "AUTO OPN." window to re-
move the P.C.B. from the memory of the machine whenever necessary.
2122000 Operator's Error Screen was not found.
(Cause 1) The screen clamping cancel check sensor (BPS094) is turned OFF.
(Remedy 1) Install the screen and re-start the operation.
When an error occurs even though the screen is installed, it is required to
adjust the sensor position or replace the sensor with a new one.
Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 71 AFU01ETRP
