Pattern Program Date of Preparation Comment 1 Prepared by Comment 2 PCB Backup Chuck Stage Select Backup Jig/Backup Pin/V acuum Plate PCB W arpage Protection OFF/ON V acuum Release Mode Before/After V acuum Rel. W ait Ti…

1. Pattern Program Data Sheets

Pattern Program Date of Preparation

Comment 1 Prepared by

Comment 2

(1) Operation Data

P.C.B. Data

P.C.B. Size X (Horizontal)

Y (Vertical)

T (Thickness)

P.C.B. Origin Offset X (Horizontal) +/-

Y (Vertical) +/-

Operation Mode Print/Pass

Print Area Origin +/-

Depth +/-

Print Data

Screen Basis Center Reference/Front Reference

/Rear Reference

Round-Way Printing ON/OFF

Frame Select 650×550/550×550/600×550/550×650

Printing Press. [N] Front N

Rear N

Squeegee Select 270/350

Squeegee Spd. For.

Back.

Screen Distance +/-

Separation Mode PCB Down/Squeegee Up

Separation Speed

Separation Acc.

Separate Distance

Prntng Correction (Back) X +/-

Y +/-

θ +/-

Prntng Correction (For.) X +/-

Y +/-

θ +/-

Screen Offset [mm] X +/-

Y +/-

0106-002 Chapter 1 5 2 AFU01EDTP

1. Pattern Program Data Sheets

Pattern Program Date of Preparation

Comment 1 Prepared by

Comment 2

PCB Backup

Chuck Stage Select Backup Jig/Backup Pin/Vacuum Plate

PCB Warpage Protection OFF/ON

Vacuum Release Mode Before/After

Vacuum Rel. Wait Time [sec]

seconds

PCB Clamp Offset Timing [sec]

seconds

Position [mm] +/-

Bef.Clamp Fll Speed/10%Down/20%Down/30%Down/

Bkup Spd. 40%Down/50%Down/ 60%Down/70%Down/

80%

Down/90%Down

Aft.Clamp Fll Speed/10%Down/20%Down/30%Down/

Bkup Spd. 40%Down/50%Down/ 60%Down/70%Down/

80%/

Down/90%Down

PCB Stopper Offset Y [mm] +/-

PCB Cut Offset [mm]

PEC Recognition

P.E.C. Recog. Function OFF/1PT./2PT./3PT.

Center Recognition OFF/ON

Fiducial Mark #1 X (Horizontal)

Y (Vertical)

Code

Fiducial Mark #2 X (Horizontal)

Y (Vertical)

Code

Recog Adjust Correct OFF/ON

Recog Adjust Point X (Horizontal)

Y (Vertical)

1. Pattern Program Data Sheets

0106-002 Chapter 1 5 3 AFU01EDTP

Pattern Program Date of Preparation

Comment 1 Prepared by

Comment 2

Screen Recognition

Scr. Recog Function OFF/1PT./2PT./3PT.

Center Recognition OFF/ON

Fiducial Mark #1 X (Horizontal)

Y (Vertical)

Code

Fiducial Mark #2 X (Horizontal)

Y (Vertical)

Code

Mark Data

Code Figure Size D1 Size D2 Rcg Area Pol. Level Light

Bright/Dark High/Middle/Low Normal

Setup Data

All Conveyor Setup ON/OFF

Two Camera Auto Calib. ON/OFF

Screen Recog ON/OFF

Automatic Stop

Hand Cleaning Stop (PCB) pcs.

Hand Cleaning Stop (CLNG.) times

Solv. Empty Stop (CLNG.) times

Paste Supply Interval Mode Paste Detect/Print PCB

Paste Empty Stop (PCB) pcs.

Paste Detect pcs.

1. Pattern Program Data Sheets

0106-002 Chapter 1 5 4 AFU01EDTP
