Error ID Item Description 1323000 P .C.B. Chuck P .C.B. clamp move error When the P .C.B. horizontal clamping function was manually activated, the P .C.B. clamp- ing forward limit sensor (BPH050) was not turned ON within…
Error ID Item Description
1319000 Conveyor Stopper P.C.B. was took on output conveyor.
Interlock
(Cause 1) A P.C.B. is still on the output conveyor.
(Cause 2) The P.C.B. arrival and passage check sensors (BPH044 and BPH045) are
defective.
(Remedy 1) Remove the P.C.B. and re-start the operation.
(Remedy 2) Check how the sensors are working in "Device Check" window (submenu).
When the sensors are not working, it is required to replace the sensors
with new ones. Contact our service personnel for details.
1320000 Table Section P.C.B. stopper error
Stopper
(Cause 1) The position of the upper limit sensor (BPS070) is shifted from the correct
one.
(Cause 2) The upper limit sensor is defective.
(Cause 3) The stopper cylinder is malfunctioning.
(Remedy 1) Readjust the sensor position.
(Refer to the separately attached paper.)
(Remedy 2) Check how the sensor is working in "Device Check" window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
(Remedy 3) Contact our service personnel for details.
1321000 P.C.B. Chuck P.C.B. chuck missed.
(Cause 1) The P.C.B. had come off when the P.C.B. was clamped.
(Cause 2) The P.C.B. clamping forward limit sensor (BPH050) is defective.
(Remedy 1) Adjust the P.C.B. clamping pressure.
Set a parameter (deceleration value) in the "Aft.Clamp Bkup Spd." text
box of "PCB Clamp Offset" in the "PCB Backup" tab sheet.
(Remedy 2) Check how the sensor is working in "Device Check" window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 51 AFU01ETRP
Error ID Item Description
1323000 P.C.B. Chuck P.C.B. clamp move error
When the P.C.B. horizontal clamping function was manually activated, the P.C.B. clamp-
ing forward limit sensor (BPH050) was not turned ON within the specified time.
Even if an error occurs when this manual operation is performed with the P.C.B. set in
the table section, it is not regarded as an error.
(Cause 1) The P.C.B. clamping pressure is too low.
(Cause 2) The P.C.B. clamping forward limit sensor is defective.
(Remedy 1) Adjust the P.C.B. clamping pressure.
(Remedy 2) Check how the sensor is working in "Device Check" window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
1401000 Squeegee Table-Z Axis is not at print pos.
Up/Down Axis
(Cause 1) The table has not moved up yet. (during the manual operation)
(Remedy 1) Move up the table and re-start the operation.
1402000 Squeegee Squeegee Up/Down cylinder moving error
Up/Down Axis
(Cause 1) The position of the upper limit sensors (BPS060 and BPS062) is shifted
from the correct one.
(Cause 2) The upper limit sensor is defective.
(Cause 3) The squeegee cylinder is malfunctioning.
(Remedy 1) Adjust the cylinder sensor position.
(Remedy 2) Check how the sensors are working in "Device Check" window (submenu).
When the sensors are not working, it is required to replace the sensors
with new ones. Contact our service personnel for details.
(Remedy 3) Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 52
Error ID Item Description
1403000 Printing Pressure Front squeegee printing pressure exceeded upper set range.
Setting
1404000 Printing Pressure Rear squeegee printing pressure exceeded upper set range.
Setting
(Cause 1) The feedback data is corrupted.
(Remedy 1) Press the [FeedBack DataClear] button in the "Printing Pressure" tab
sheet. (Vol.1, Chapter 2, Section 5, 2.5 "Printing Pressure" Tab)
1405000 Printing Pressure Printing pressure exceeded upper range.
Setting
(Cause 1) The output value of the load cell is abnormal.
(Remedy 1) Check for any foreign substances around the squeegee up/down cylin-
der and confirm that the squeegee is correctly installed.
When the same error still occurs, contact our service personnel for de-
tails.
1406000 Printing Pressure Printing pressure exceeded upper range. (Average Value)
Setting
(Cause 1) The printing pressure got out of the specified one during printing.
(Remedy 1) Check the parameter set in the "Average" text box of the "Printing Press.
Error Setting" group box in the "Operation Mode" tab sheet.
Increase the value when the threshold severer than required is specified.
(Target Value: 50N)
Check if the amount of the supplied solder paste is too much or not.
When the same error still occurs after the above-described checking,
contact our service personnel for details.
1407000 Printing Pressure Front squeegee pressure exceeded minimum limit.
Setting
1408000 Printing Pressure Rear squeegee pressure exceeded minimum limit.
Setting
(Cause 1) The feedback data is corrupted.
(Remedy 1) Press the [FeedBack DataClear] button in the "Printing Pressure" tab
sheet. (Vol.1, Chapter 2, Section 5, 2.5 "Printing Pressure" Tab)
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 53 AFU01ETRP
