Error ID Item Description
1210000 Output Conveyor The distance Table-X axis and outp.conv. exceeded min.limit.
Width Interlock
(Cause 1) The table X axis interlock sensors (BPH056 and BPH057) are defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The conveyor width was adjusted when the table X axis was brought close
to the right or the left. (during the manual operation)
(Remedy 1) Check how the sensors are working in "Device Check" window (submenu).
When the sensors are not working, it is required to replace the sensors
with new ones. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation. When the same error still occurs,
contact our service personnel for details.
(Remedy 3) Perform the zeroing operation and re-start the operation.
1211000 Output Conveyor PCB was exist on conveyor.
Width Interlock
(Cause 1) No operation is possible because a P.C.B. still exists on the conveyor.
(Cause 2) The P.C.B. detection sensor (BPH044 and BPH045) are defective.
(Remedy 1) Remove the P.C.B. and re-start the operation.
(Remedy 2) Check how the sensors are working in "Device Check" window (submenu).
When the sensors are not working, it is required to replace the sensors
with new ones. Contact our service personnel for details.
1212000 Output Conveyor The data was detected outside of the possible range.
Width Data
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If the machine is not reset to its normal condition, shut down the power of
the machine once and power up the machine again. After that, re-start
the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 46 AFU01ETRP
Error ID Item Description
1213000 Output Conveyor Zeroing Opn. Not Complete
Width Origin
(Cause 1) The motor axis was activated before the zeroing operation was completed.
(Remedy 1) Perform the zeroing operation.
1301000 P.C.B. Supply P.C.B. transfer signal was not off after P.C.B. detect.
1302000 P.C.B. Supply P.C.B. transfer signal is off before P.C.B. detect.
(Cause 1) Communication Error with Input Machine
(Remedy 1) Check the P.C.B. transfer signal from the input machine in the "Org./
Signal Info." tab sheet.
When the problem cannot be solved, contact our service personnel for
details.
1303000 Input Conveyor PCB from inp. machine was not received within specified
Overtime time.
(Cause 1) The set value of the timer is too short.
(Cause 2) The conveyor speed is too slow.
(Cause 3) The P.C.B. detection sensor (BPH041) is not working.
(Remedy 1) Set a larger parameter in the "Output Conveyor" text box of the "Timer
Setting (sec)" group box in the "Transfer Mode Set-up" tab sheet.
(Remedy 2) Turn up the variable resistor of the L conveyor speed control.
(Remedy 3) Check how the sensor is working in "Device Check" window (submenu).
When the sensor is not working, it is required to adjust the sensor posi-
tion or replace the sensor with a new one.
Contact our service personnel for details.
1304000 Output Conveyor PCB was not transferred to outp.conv. within specified time.
Overtime
(Cause 1) The set value of the timer is too short.
(Cause 2) Communication Error with Output Machine
(Remedy 1) Set a larger parameter in the "Output Conveyor" text box of the "Timer
Setting (sec)" group box in the "Transfer Mode Set-up" tab sheet.
(Remedy 2) Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 47 AFU01ETRP
Error ID Item Description
1305000 P.C.B. Transfer PCB transfer from inp. conv. was not completed within speci-
Overtime fied time.
(Cause 1) The conveyor speed is too slow.
(Cause 2) The P.C.B. detection sensor (BPH071) is not working.
(Remedy 1) Turn up the variable resistor of the L conveyor speed control.
(Remedy 2) Check how the sensor is working in "Device Check" window (submenu).
When the sensor is not working, it is required to adjust the sensor posi-
tion or replace the sensor with a new one.
Contact our service personnel for details.
1306000 P.C.B. Transfer PCB transfer to outp.conv. was not completed within speci-
Overtime fied time.
(Cause 1) The P.C.B. arrival check sensor (BPH044) is not working.
(Remedy 1) Check how the sensor is working in "Device Check" window (submenu).
When the sensor is not working, it is required to adjust the sensor posi-
tion or replace the sensor with a new one.
Contact our service personnel for details.
1307000 P.C.B. Transfer PCB was not transferred from outp.conv. within specified
Overtime time.
(Cause 1) The P.C.B. passage check sensor (BPH045) is not set in the E/NR (Light
Emitted and Not Received) or the E/R (Light Emitted and Received) mode.
(Remedy 1) Check how the sensor is working in "Device Check" window (submenu).
When the sensor is not working, it is required to adjust the sensor posi-
tion or replace the sensor with a new one.
Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 48 AFU01ETRP
