Error ID Item Description
1901042 Screen Fiducial Recognition system error.
Mark #1
1901043 Screen Fiducial Recognition system error.
Mark #1
1901044 Screen Fiducial Could not get image at normal light.
Mark #1
1901045 Screen Fiducial Could not get image at ring light.
Mark #1
1901046 Screen Fiducial Field no. was out of range.
Mark #1
1901047 Screen Fiducial Pinting test failed.
Mark #1
1901048 Screen Fiducial Could not get screen image
Mark #1
1901049 Screen Fiducial Could not move indpection window.
Mark #1
1901050 Screen Fiducial Could not cut indpection window.
Mark #1
1901051 Screen Fiducial Could not soecified opening area size.
Mark #1
1901052 Screen Fiducial Could not send inspection window data.
Mark #1
1901053 Screen Fiducial Could not reimage bridge insoection window.
Mark #1
1901054 Screen Fiducial Could not reimage bridge insoection window(rotation).
Mark #1
1901055 Screen Fiducial PAD area soze exceeds the max eange(6.5mm
2
).
Mark #1
1901056 Screen Fiducial Recog. transaction time over.
Mark #1
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
1902000 Screen Fiducial (Same as "Fiducial Mark #1")
Mark #2
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 66 AFU01ETRP
Error ID Item Description
1904000 Screen Recognition (Same as "Fiducial Mark #1")
Test
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
1906000 Screen Recognition (Same as "Fiducial Mark #1")
Camera
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2001000 Cleaning Interlock P.E.C Recog-Y Axis is not at safety area.
(Cause 1) The cleaning nozzle was moved up when the P.C.B. recognition Y axis was
not located at its front escape position (origin position).
(during the manual operation)
(Cause 2) The P.C.B. recognition Y-axis near origin sensor (BPH331) is defective.
(Cause 3) The operation timing is shifted from the normal one.
(Remedy 1) Zero the P.C.B. recognition Y axis and re-start the operation.
(Remedy 2) Zero the P.C.B. recognition Y axis.
When the P.C.B. recognition Y axis cannot be zeroed, it is required to
replace the sensor with a new one. Contact our service personnel for
details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 67 AFU01ETRP
Error ID Item Description
2005000 Cleaning Cleaning nozzle up/down cylinder moving error
(Cause 1) The cleaning nozzle was moved up when the P.C.B. recognition Y axis was
not located at its front escape position (origin position).
(during the manual operation)
(Cause 2) The P.C.B. recognition Y-axis near origin sensor (BPH331) is defective.
(Cause 3) The operation timing is shifted from the normal one.
(Remedy 1) Zero the P.C.B. recognition Y axis and re-start the operation.
(Remedy 2) Zero the P.C.B. recognition Y axis.
When the P.C.B. recognition Y axis cannot be zeroed, it is required to
replace the sensor with a new one. Contact our service personnel for
details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2006000 Cleaning Cleaning paper feed error
(Cause 1) The paper feeder pitch detection sensor (BPH082) is not working.
(Cause 2) The inside of the cleaning paper roller is torn, making the rotation of the
paper cylinder idle.
(Cause 3) The belt of the take-up motor is not engaged correctly (some teeth not mesh-
ing with the belt).
(Remedy 1) Check for any dirt around the sensor and how the sensor is working in
the "DEVICE CHECK" window (submenu).
When the sensor is not working, it is required to adjust the sensor posi-
tion or replace the sensor with a new one.
Contact our service personnel for details.
(Remedy 2) Check the internal condition of the paper roller. If some area is torn, re-
place it with another one.
(Remedy 3) When you hear the sounds, indicating that some teeth do not mesh cor-
rectly with the belt during the take-up operation, it is required to adjust the
belt tension.
Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 68 AFU01ETRP
