1 - 4
Student Guide CAN BUS Workshop
1 Operational safety Edition 06/2008
4
1.2 Warning labels
1.2.1 Warning labels on the machine
Their design meets the requirements of ISO 3864-2 and ANSI Z535.4.
1.2.1.1 Warning label W201
1.2.1.2 Warning label W203
1.2.1.3 Warning label W204
SAFE OPERATION OF THE MACHINE
Safe operation of the machine depends absolutely
on the operator being familiar with the user manual
and safety instructions and putting them into effect.
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms
and hands.
Do not reach into the machine while it is running
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms
and hands.
Do not reach into the machine while it is running
1 - 5
Student Guide CAN BUS Workshop
Edition 06/2008 1 Operational safety
5
1.2.1.4 Warning label W202 on the gantries
Fig. 1.2 - 1 Warning label W202 on the gantries, item no. 03009341-01
WARNING!
Powerful permanent magnetic fields inside the machine
RISK OF DEATH!
Risk of death for persons with active implants (e.g. pacemakers, insulin pumps, defibrillators).
DANGER OF CRUSHING!
Danger of crushing for persons with passive metal implants (e.g. plates, screws).
Do not reach into the machine or bend towards it when the protective covers are open.
Do not bring any metal objects into the area.
1 - 6
Student Guide CAN BUS Workshop
1 Operational safety Edition 06/2008
6
1.2.1.5 Warning label W205 on the tape cutter
Fig. 1.2 - 2 Warning label W205 on the bottom of the tape cutter
WARNING 1
If you wish to do work on the tape cutter, you must disconnect the machine from the mains sup-
ply and the compressed air supply.
Wait until the operating pressure has dropped to 0 MPa.
RISK OF CUTTING!
Danger of cutting is present even when the
machine is switched off
