1 - 18 Siplace C AN T est Box 1 CAN T est Box Edition 04/200 8 18 Fig. 1.9 - 6 Short circuit between CAN_H and CAN_L 1.9.3 CAN T elegrams With and Without Error Frames Fig. 1.9 - 7 CAN telegram without errors CAN _H lev …
1 - 17
Siplace CAN Test Box
Edition 04/2008 1 CAN Test Box
17
1.9.2 CAN Bus Short Circuit
Fig. 1.9 - 4 Short circuit between CAN_H and GND
Fig. 1.9 - 5 Short circuit between CAN_L and GND
CAN _H level
CAN _L level
CAN _H level
CAN _L level
1 - 18
Siplace CAN Test Box
1 CAN Test Box Edition 04/2008
18
Fig. 1.9 - 6 Short circuit between CAN_H and CAN_L
1.9.3 CAN Telegrams With and Without Error Frames
Fig. 1.9 - 7 CAN telegram without errors
CAN _H level
CAN _L level
CAN _H level
CAN _L level
Error Frame Counter
1 - 19
Siplace CAN Test Box
Edition 04/2008 1 CAN Test Box
19
Fig. 1.9 - 8 CAN telegram with errors
Fig. 1.9 - 9 CAN telegram with errors
CAN _H level
CAN _L level
Error Frame Counter
CAN _H level
CAN _L level
Error Frame
Counter
