CACCIA Manual 1 Caccia Student Guide Issue 04/2007 EN 109 1 Comments:
1 Caccia Student Guide CACCIA Manual
Issue 04/2007 EN
108
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
E 58 (C500 Head interface environment)
8 bit Procssor on headadapter available or remove the 8
bit processor
E 59 (C500 Head interface environment)
board type recognition head interface and head adapter are
not conform --> programming the correct board type.
E 5A (C500 Head interface environment)
unknown head adapter --> programming the correct board
type.
E 5b (C500 Head interface environment)
unknown head interface and head adapter --> program-
ming the correct board type.
E 5C (C500 Head interface environment)
unknown head interface --> programming the correct board
type.
E 5d (C500 Head interface environment)
unknown intermediate distributor --> programming the cor-
rect board type.
E 5E (C500 Head interface environment)
unknown Head adapter and intermediate distributor -->
programming the correct board type.
E 5F (C500 Head interface environment)
unknown head adapter- and intermediate distributor
eeprom.
Error messages TQM Modul
E = Error
Description
CACCIA Manual 1 Caccia Student Guide
Issue 04/2007 EN
109
1
Comments:
1 Caccia Student Guide CACCIA Manual
Issue 04/2007 EN
110
1
Comments:
