13 Production Tools / Set-Up User Manu al Line Computer UNIX 13.1 Set-Up Editor (Feeder Part and W PC Editors) Software Version 501.xx 01/99 Issue 13 - 30 13.1.4 EDIT Menu The EDIT menu which is availa ble on the menu ba…

User Manual Line Computer UNIX 13 Production Tools / Set-Up

Software Version 501.xx 01/99 Issue 13.1 Set-Up Editor (Feeder Part and WPC Editors)

13 - 29

EDIT

The EDIT menu contains the following option:

Reset

This function cannot be executed as of yet.

Identification Field

The identification field contains the following data which cannot be edited:

Station:

Name of the current station including Overall system/subline/line/set-up/

station name

Mach.opt.:

Name of the RV head

Location:

Name of the location where the machine option is set up

Command area

Commands are available in the command area by means of which nozzles can be allocated, moved and deleted.

For a commond to be executed, it must be clicked on. The icon turns gray then.

Proceed further as described in section 13.1.3.6.

Create

If this icon is active, a nozzle can be allocated to a segment of the RV head.

Move

If this icon is active, a nozzle can be moved to another segment within the RV head.

Delete

If this icon is active, a nozzle can be deleted from a segment within the RV head.

Selection Field "Segments"

This selection field contains a listing of the 12 (or 6) segments of the RV head in numerical sequence.

The allocation of nozzles to the empty segments can be made as required.

Selection Field "Nozzle"

This selection field contains a listing of all factory-defined nozzles. This list cannot be changed.

13 Production Tools / Set-Up User Manual Line Computer UNIX

13.1 Set-Up Editor (Feeder Part and WPC Editors) Software Version 501.xx 01/99 Issue

13 - 30

13.1.4 EDIT Menu

The EDIT menu which is available on the menu bar of both editors contains the following option:

° RI-File

The option is preceded by a small circle (°) indicating that the option is not activated. As soon as it is

selected, the circle is displayed with an "X" through it (

) indicating that the option is activated. By

clicking on the RI-File again, the file is deactivated.

13.1.4.1 RI-File

Clicking on the "RI-File" option on the EDIT menu causes the Set-up info file to be activated. This file is part of

the Feeder Editor and contains the allocations of components and package forms to specific feeders and waffle-

pack trays. The Feeder Part Editor and WPC Editor will access these allocations when the "RI-File" option is

activated.

Upon creating the set-up, it then suffices to allocate the component to a track or level, respectively. The program

then automatically sets the feeder defined for the component, or the defined waffle-pack tray together with the

particular component onto this track or level, respectively. All existing correction values are adopted.

If no allocation can be found for a particular component, a corresponding error message is displayed which

must be acknowledged. The component must then be set up with the aid of the feeder list, or an appropriate

allocation must be newly defined in the Feeder Editor.

If changes are made in the Set-up infor file with the "RI-File" option activated, these changes will not be

automatically accepted. The "RI-File" option must be turned off and then turned on again for the current changes

to be able to be accepted.

The "RI-File" option permits an effective and error-free creation of set-ups and its use should be given

preference.

User Manual Line Computer UNIX 13 Production Tools / Set-Up

Software Version 501.xx 01/99 Issue 13.1 Set-Up Editor (Feeder Part and WPC Editors)

13 - 31

13.1.5 Command area "Action"

The commands Select, Allocate, Delete and Move are available in the Set-Up Data Editor. They are symbolized

by icons. Clicking on the icons allows the mode to be determined in which the Set-Up Data Editor is to operate.

The selected mode remains active until another icon is clicked on. The mode is valid for all open Feeder Part

Editors alike.

All objects must be clicked on for a command to be executed on them. In the non-selected state they are

displayed in dark-blue, in the selected state in light-blue.

The divisions and compartments of the feeders and waffle-pack trays must be clicked on so that components

can be allocated to them. In the non-selected state the empty divisions are outlined in dark-blue. As soon as

they are selected, they are displayed in light-blue.

Overview of the meaning of the colors:

dark-blue:

object is non-selected; division or divisions are empty and non-selected.

light-blue:

object is selected; division or divisions are empty and selected.

dark-green:

division or divisions are occupied and non-selected.

light-green:

division or divisions are occupied and selected.

Select

When this icon is active, the editor is in the selection mode. This mode is a type of "neutral" mode in

which no actions can be executed. The selection mode is active when the Set-Up Data Editor is

opened.

The selection mode is selected to invoke the Packaging Editor and the Machine Options Editor.

●

Click on .

●

Click on a feeder division or the waffle-pack tray compartments (divisions).

The division or divisions are highlighted.

●

Click on an option of the SERVICES menu.

The respective editor is opened.

●

Make the required entries.
