17.2 From the Placement Pro
g
ram to the Assembly User Manual Line Computer UNIX
17.2.6 Flowchart Set-Up Generation Software Version 501.xx 01/99 Issue
17 - 8
17.2.6 Flowchart Set-Up Generation
Open
Optimization Dialog
S.17-52
Create lot file
S.17-52
Desktop
Edit lot file
S.17-52
Save lot file
S.17-52
Generate
basic optimization data
S.17-52
Optimization Dialog
Start optimization
for lot file
S.17-54
Start producibility check
for lot file
S.17-54
Display and print
optimized set-up
S.17-54
Set-Up Modification
Job Control
Lot Handling
Section 17.4.1
Automatic
Set-Up Generation
Section 17.4.2
Generator
User Manual Line Computer UNIX 17.2 From the Placement Pro
g
ram to the Assembly
Software Version 501.xx 01/99 Issue 17.2.6 Flowchart Set-Up Generation
17 - 9
Open
Set-Up Editor/Feeder Part Editor
S.17-56
Delete feeders,
which are not required
S.17-56
Allocate new feeders
to the tracks
S.17-56
Desktop
Allocate components
to the feeders
S.17-56
Adjust vibration time
and pick-up angle
S.17-58
Save set-up
S.17-58
Set-Up Editor/
Manual
Set-Up Adjustment
Section 17.4.3
Feeder Part Editor
Open
Set-Up Editor/WPC Editor
S.17-58
17.2 From the Placement Pro
g
ram to the Assembly User Manual Line Computer UNIX
17.2.6 Flowchart Set-Up Generation Software Version 501.xx 01/99 Issue
17 - 10
Allocate component
to tray
S.17-60
Save set-up
S.17-60
Allocate tray to
Waffle-Pack Changer
S.17-58
Set-Up Editor/
Define tray
S.17-58
Open Line Control
S.17-60
Adjust conveyor width
S.17-60
Line Control
WPC Editor
