2 General Information on Using the Program User Manual Line Computer UNIX
2.1 Basics Software Version 501.xx 01/99 Issue
2 - 8
2.1.2 On-Screen Help
The line computer software comprises two Help programs that can be called up separately (see section 2.5.3 ).
- Online Help
The Online Help is a comprehensive (partly graphical) help program that enables detailed information
about commands, editing fields, buttons and given functions to be called up while working. When the
online screen Help system is active, all areas of the application windows are "sensitive" that serve as
a link to more detailed information about the current topic (e.g. editing fields, menus, commands, etc.).
NOTE
Details on how to use the Online Help are contained in section 2.5.3.
- Help Index
The Help Index is a help program by means of which detailed information about a selected topic can
be provided in a separate window. Integrated in the help information are
sensitive text areas
(branch
addresses) with the aid of which a link to other help topics or more detailed information about the
current topic can be established when they are clicked on with the mouse.
NOTE
Basic information about working with the Help Index is contained in section 2.5.3.1.
2.1.3 Terminating a Working Session on the Line Computer
CAUTION
On no account may the line computer be simply switched off in the middle of the program! The software must
be allowed to shut itself down safely as described below! Only when this procedure is adhered to can all open
files be closed!
If the line computer is simply switched off, considerable data loss may be the result!
● Point with the mouse cursor to the right (or lower) border of the screen.
The mouse cursor has an x shape.
● Press and hold left mouse button.
The main menu (Root Menu) appears (see section 2.2.2).
● Move mouse cursor over the menu option Shutdown and release the mouse button.
The following dialog box appears:
User Manual Line Computer UNIX 2 General Information on Using the Program
Software Version 501.xx 01/99 Issue 2.1 Basics
2 - 9
● Click on yes.
The computer "powers itself down".
When the procedure is terminated, the following message is displayed on the screen:
● Switch off UPS and Monitor.
CAUTION
To prevent any communication problems between line computer and station computer(s) from occurring,
the following steps should be performed:
é Turn off all stations after having terminated the line computer session by "LR-End" ("Shutdown").
é When restarting the line computer by means of "LR-Start" (or booting the LC, see section 2.1.1),
do not turn on the stations before the root window ("Desktop") is displayed on the screen.
really shutdown?
yes no
** Safe to Power Off **
-or-
** Press Any Key to Reboot **
