FlexTRAK-OH Material Handling System IOM Manual Troubleshooting
© 2023 Nordson Corporation 6-17
No. Alarm Message Cause Recovery
23
STN50 Magazine Not Present At
Bottom Gripper: Unloader Lifter
Gripper
Loader –
overhead
conveyor
Place correct treated strip magazine size into
loader – overhead conveyor.
Conveyor
Ensure conveyor is rotated and able to move
the magazine until the magazine stopper
location.
Magazine present
sensor
Check sensor function (I011.04 – unloader
bottom mag present sensor).
24
STN50 Please Clear Magazine
Before Auto Run: Unloader Lifter
Unloader lifter
Z-axis
Remove the magazine from lifter axis 9:
Z-axis.
Sensor
Check sensor function (I009.10 – mag present
sensor).
25
STN50 Gripper Bottom Grip Present
Sensor Fault: Unloader Lifter Gripper
Gripper detection
shaft
Ensure the detection shaft can reach the
sensor slot without any obstruction.
Sensor
Check sensor function (I011.10 – unloader
gripper bottom present sensor).
26
STN50 Gripper Top Grip Present
Sensor Fault: Unloader Lifter Gripper
Gripper detection
shaft
Ensure the detection shaft can reach the
sensor slot without any obstruction.
Sensor
Check sensor function (I011.07 – unloader
gripper top present sensor).
27
STN50 Magazine Datum Point
Sensor Fault
Sensor
Check sensor function (I012.12 – magazine
datum point sensor).
6.3.8 Station 60 – Alarm Error Messages
Table 6-8 Station 50 – Alarm Error Messages
No.
Alarm Message
Cause
Recovery
1
CYL6001 Extend Jam: Conveyor
Input Magazine Hold Cylinder
N/A See Table 6-2, Item 5(a).
2
CYL6001 Retract Jam: Conveyor
Input Magazine Hold Cylinder
N/A See Table 6-2, Item 5(b).
3
CYL6002 Extend Jam: Conveyor
Input Magazine Puller
N/A See Table 6-2, Item 5(a).
4
CYL6002 Retract Jam: Conveyor
Input Magazine Puller
N/A See Table 6-2, Item 5(b).
5
CYL6003 Extend Jam: Conveyor
Output Magazine Hold Cylinder
N/A See Table 6-2, Item 5(a).
6
CYL6003 Retract Jam: Conveyor
Output Magazine Hold Cylinder
N/A See Table 6-2, Item 5(b).
7
CYL6004 Extend Jam: Conveyor
Output Magazine Pusher
N/A See Table 6-2, Item 5(a).
8
CYL6004 Retract Jam: Conveyor
Output Magazine Pusher
N/A See Table 6-2, Item 5(b).
9
STN60 Magazine On Conveyor
Timeout
Magazine
Magazine on conveyor more than 20
seconds (default timeout).
Sensor
Magazine sensor does not turn on (I007.12
– mag detect 1 sensor).
© 2023 Nordson Corporation 7-1
7 Parts Replacement
7.1 Overview
This section includes general information for ordering recommended spares and replacement parts for the
FlexTRAK-OH Material Handler. This section includes the following topics:
• Parts Ordering Information
• Unpacking and Inspecting Replacement Parts
• Warranty
• Cleaning and Inspection
• Credit and Exchanges
• Spare Parts List
• Record Keeping
WARNING! Parts replacement should only be performed by a trained service technician.
March assumes no liability for personal injury or property damage that may
occur as a result of parts replaced by a non-certified technician.
7.2 Safety First
Operation of your FlexTRAK-OH Material Handler involves mechanical devices, air pressure, and
electrical power. It is essential that every person servicing or operating the FlexTRAK-OH fully
understands all hazards, risks, and safety precautions. When properly operated and maintained, the
FlexTRAK-OH Material Handler should be safe and reliable. Refer to Section 2 - Safety before replacing
any parts
.
WARNING! DO NOT hot swap connections when working with electrical and pneumatic
power supplies. Turn the main circuit break off before disconnecting the external
power plug from the facility.
7.3 Parts Ordering Information
7.3.1 Placing Your Order
Customers can order spare parts by contacting March Customer Service. Contact information is listed in
the front of this manual. Spare parts can also be ordered online through our Internet Web Store. To set up
a web store account, send an email to americas.es.cs@nordson.com
.
When ordering parts, be prepared to provide the following information:
• Your Company Name
• Billing Address
• Shipping Address
• Part Number and Description of Part
• Purchase Order Number
• Quantity
• Dispensing System Serial Number
(found on back panel)
• Shipping Instructions with Collect
Account Number
