FlexTRAK-OH Material Handli ng System IOM Manual Parts Replacement © 2023 Nordson C orporation 7-59 7.12.5 Mobile Cont rol Pend ant No. Part Numb er Des cription Estimated Li fe Span (cycles) Quantity 1 0002 - 01001 - 00…
FlexTRAK-OH Material Handling System IOM Manual Parts Replacement
7-58 © 2023 Nordson Corporation
7.12.4 AC and DC Air Flow Vent
No. Part Number Description
Estimated Life
Span (cycles)
Quantity
1 0002-17002-00048
TOYO MINIBLOWER TM Series 24VDC
PLASTIC HOUSING
30,000 1
Figure 7-55 AC and DC Air Flow Vent
FlexTRAK-OH Material Handling System IOM Manual Parts Replacement
© 2023 Nordson Corporation 7-59
7.12.5 Mobile Control Pendant
No. Part Number Description
Estimated Life
Span (cycles)
Quantity
1 0002-01001-00259
EMERGENCY STOP LATCHING
PUSHBUTTON,1NO,2NC
300,000 1
2 0002-14003-00056
TOUCHSCREEN, 7 INCH, TFT LCD,
COLOR, 800 × 480 DOTS , USB HOST,
ETHERNET
1 year 1
Figure 7-56 Mobile Control Pendant
FlexTRAK-OH Material Handling System IOM Manual Parts Replacement
7-60 © 2023 Nordson Corporation
7.12.6 Main Machine Structure
No. Part Number Description
Estimated Life
Span (cycles)
Quantity
1 0002-15002-00023 Q-LIGHT LED LIGHT BARS 30,000 1
2 0002-10014-00199 SAIB-M8-3P 1 year 1
3 0002-10014-00198 SAIS-M8-3P 1 year 1
Figure 7-57 Main Machine Structure
