FlexTRAK-OH Material Handling System IOM Manual Specifications
© 2023 Nordson Corporation 8-7
8.5.2 Human Body Minimum Clearance
Table 8-3 Human Body Minimum Clearance
Body Posture
Job Activities
Height Level
Illustration Minimum Clearance
Sitting on floor Ground
Overhead clearance,
A = 1220 mm
Forward horizontal
clearance,
B = 790 mm
Squatting Ground to center
Overhead clearance,
A = 1000 mm
Forward horizontal
clearance,
B = 690 mm
Stooping
Ground to center,
center
Overhead clearance,
A = 1450 mm
Forward horizontal
clearance,
B = 1020 mm
FlexTRAK-OH Material Handling System IOM Manual Specifications
8-8 © 2023 Nordson Corporation
Body Posture
Job Activities
Height Level
Illustration Minimum Clearance
Standing and
walking
Center, center to top
Overhead clearance,
A = 1980 mm
Forward horizontal
clearance,
B = 690 mm
Lower body clearance,
C = 508 mm
All body
posture
Center, center to top
Horizontal clearance for
upper body,
D = 610 mm
FlexTRAK-OH Material Handling System IOM Manual Specifications
© 2023 Nordson Corporation 8-9
8.6 System Block Diagram
Figure 8-4 FlexTRAK-OH System Block Diagram
NOTE Refer to the FlexTRAK-SHS Loader and Unloader Conveyor Electrical Schematics
(Document Number: NM001-CD) for further details.
