1.3 Precautions during Operation 0004-002 12 Tg0246-PM-OP 1.3 Precautions during Operation • When the tower lamp (green) is ON, it shows that the static machine is in the “automatic” mode (awaiting mode). • When there is…

1.2 Precautions before Operation

9910-001 11 Tg0246-PM-OP

1.2 Precautions before Operation

• Always check the machine before automatic operation.

• Only a trained personnel should operate the machine.

• Make certain that no one (including part of body and clothes) or foreign ob-

jects remain within the moving parts of the machine. Then, check safety and

power up the machine to start operation.

Do not start the machine unless those working in the immediate

area of the machine are aware of hazards from

• Make sure that only qualified personnel remain within the operation area of

the machine.

• In principle, the buttons on the operation panel and the keys on the touch

screen must be operated by only one person. If there are more than one, ensure

good communication by giving loud verbal instructions.

WARNING

CAUTION

WARNING

CAUTION

1.3 Precautions during Operation

0004-002 12 Tg0246-PM-OP

1.3 Precautions during Operation

• When the tower lamp (green) is ON, it shows that the static machine is in the

“automatic” mode (awaiting mode).

• When there is a problem with the machine, locate the cause and assess the

condition. After the problem has been rectified, turn off power supply (if re-

quired) and follow reset procedures.

• Ensure personnel (part of body and clothes) and foreign objects remain clear

of the moving parts of the machine.

• Keep one’s face and hands away from any moving part of the machine.

Power OFF Mode

• When the machine stops due to error during automatic operation, check the

cause of the error through the operation monitor and turn off the power. Keep

the power off until the cause is completely resolved.

(Refer to “Volume 3 : Troubleshooting” for details.)

WARNING

CAUTION

Power Breaker

Mispicked Component

1.3 Precautions during Operation

9910-001 13 Tg0246-PM-OP

• When a pick-up error has occurred in the tape feeder, be sure to remove the

mispicked component and then start the automatic operation.

• When a pick-up error has occurred in the vibratory stick feeder, be sure to

remove the mispicked component and then start the automatic operation.

CAUTION

Mispicked Component
