Mispicked Component
1.3 Precautions during Operation
9910-001 13 Tg0246-PM-OP
• When a pick-up error has occurred in the tape feeder, be sure to remove the
mispicked component and then start the automatic operation.
• When a pick-up error has occurred in the vibratory stick feeder, be sure to
remove the mispicked component and then start the automatic operation.
CAUTION
CAUTION
Mispicked Component
1.4 Precautions in Maintenance
9910-001 14 Tg0246-PM-OP
Air Source
1.4 Precautions in Maintenance
• Before maintenance, inspection, adjustment, lubrication, or cleaning work,
turn off the power switch of the machine and the air source. Only qualified
personnel should operate the machine, following the instructions.
• Whenever maintenance work is performed, turn off the power and
air sources and lock the power breaker using the padlock.
• Designate a personnel who can have charge of the padlock key.
• If the provided padlock is lost or damaged, purchase its substi-
tute.
Power Source
WARNING
WARNING
Power Breaker
Padlock
(No. 2500 30 MM)
Padlock
(No. 2500 25 MM)
Main Valve
1.5 Other Precautions
0004-002 15 Tg0246-PM-OP
1.5 Other Precautions
• In case of earthquake, windstorm, fire, etc., stop the machine immediately,
turn off power switches and cut the power supply to the machine.
• Precautionary measures (prevention of noise generation, etc.) must be taken
for other equipment to prevent malfunctions.
• Never remove or modify any one of the main body, maintenance cover, safety
devices.
• Do not deliberately remove or modify any one of the [EMERGENCY STOP]
buttons.
• Never modify any part of the machine (especially the main body and safety
devices) for functional and safety purposes.
CAUTION
CAUTION
WARNING
WARNING
WARNING
Maintenance Cover
[EMERGENCY STOP] Buttons
Modification
Prohibited
Modification
Prohibited
