Section 3 Automatic Operation Menus 9910-001 3-1 Tg0246-PM-OP
0004-001 2-70 Tg0246-PM-OP
Section 3
Automatic Operation Menus
9910-001 3-1 Tg0246-PM-OP
1. Hierarchical Structure of Automatic Operation Dis-
plays
Automatic operation menus are described in the following hierarchical struc-
ture.
The number in ( ) shows item Nos. to be referred to in the instruction manual.
RECALL
MESSAGES
MANAGEMENT
DATA
PRODUCT
CHANGE
TEACH OFFSET
RECOVERY OPN.
TEACHING OPN.
OPERATION MODE
SEMI-AUTOMATIC
OPERATION
(4. in Section 3)
(5. in Section 3)
(6. in Section 3)
(4. in Section 4)
[AUTO OPN. SUB-MENU]
Key
SPECIAL SEL.
(Section 3 in Volume 4)
• FULL AUTO CONT [STRAT]
• FULL AUTO STEP [MOVE]
• 1 CMPNT PLACE [MOVE]
• ALTERNATE MODE
• CONVEYOR WIDTH
: Options
TRAY PICK-UP
MATRIX (Option)
(7. in Section 3)
PICK-UP
LOCATION
• CURRENT PROGRAM
• COMPONENT LIBRARY EDIT
• COMP. CARRIAGE DATA EDIT
• FEEDER (B) OFFSET
• CURRENT PROGRAM PLACE-
MENT DATA SORTING
(Item 6. of Section 3 in Volume 4)
PROGRAM
CHANGE
(3. in Section 4)
• COMPONENT MISSING CHECK
MODE
• AUTOMATIC FEEDER AXIS
ADJ. MODE
• OVERALL TACT TIME REDUC
TION
• RECOG MONITOR DISPLAY
MODE
• P.E.C. MANUAL ALIGNMENT
MODE
1. Hierarchical Structure of Automatic Operation Displays
0103-003 3-2 Tg0246-PM-OP
