5 - 11 5. PARAMETERS No. Symbol Name Initial value Unit PB40 For manufacturer setting 0.0 PB41 1125 PB42 1125 PB43 0004h PB44 0.0 PB45 0000h 5.2.2 Detail list No. Symbol Name and function Initial value Unit Setting range…
5 - 10
5. PARAMETERS
5.2 Gain/filter parameters (No.PB
)
POINT
Parameter whose symbol is preceded by * is made valid with the following
conditions.
* : Set the parameter value, switch power off once after setting, and then
switch it on again, or perform the controller reset.
5.2.1 Parameter list
No. Symbol Name Initial value Unit
PB01 FILT Adaptive tuning mode (Adaptive filter ) 0000h
PB02 VRFT
Vibration suppression control tuning mode
(advanced vibration suppression control)
0000h
PB03 For manufacturer setting 0
PB04 FFC Feed forward gain 0 %
PB05 For manufacturer setting 500
PB06 GD2 Ratio of load inertia moment to servo motor inertia moment 7.0
Multiplier
(
1)
PB07 PG1 Model loop gain 24 rad/s
PB08 PG2 Position loop gain 37 rad/s
PB09 VG2 Speed loop gain 823 rad/s
PB10 VIC Speed integral compensation 33.7 ms
PB11 VDC Speed differential compensation 980
PB12 For manufacturer setting 0
PB13 NH1 Machine resonance suppression filter 1 4500 Hz
PB14 NHQ1 Notch shape selection 1 0000h
PB15 NH2 Machine resonance suppression filter 2 4500 Hz
PB16 NHQ2 Notch shape selection 2 0000h
PB17 Automatic setting parameter
PB18 LPF Low-pass filter setting 3141 rad/s
PB19 VRF1 Vibration suppression control vibration frequency setting 100.0 Hz
PB20 VRF2 Vibration suppression control resonance frequency setting 100.0 Hz
PB21
For manufacturer setting 0.00
PB22 0.00
PB23 VFBF Low-pass filter selection 0000h
PB24 *MVS Slight vibration suppression control selection 0000h
PB25 For manufacturer setting 0000h
PB26 *CDP Gain changing selection 0000h
PB27 CDL Gain changing condition 10
PB28 CDT Gain changing time constant 1 ms
PB29 GD2B Gain changing ratio of load inertia moment to servo motor inertia moment
7.0
Multiplier
(
1)
PB30 PG2B Gain changing position loop gain 37 rad/s
PB31 VG2B Gain changing speed loop gain 823 rad/s
PB32 VICB Gain changing speed integral compensation 33.7 ms
PB33 VRF1B Gain changing vibration suppression control vibration frequency setting 100.0 Hz
PB34 VRF2B Gain changing vibration suppression control resonance frequency setting 100.0 Hz
PB35
For manufacturer setting 0.00
PB36 0.00
PB37 100
PB38 0.0
PB39 0.0
5 - 11
5. PARAMETERS
No. Symbol Name Initial value Unit
PB40
For manufacturer setting 0.0
PB41 1125
PB42 1125
PB43 0004h
PB44 0.0
PB45 0000h
5.2.2 Detail list
No. Symbol Name and function
Initial
value
Unit
Setting
range
PB01 FILT Adaptive tuning mode (adaptive filter )
Select the setting method for filter tuning. Setting this parameter to "
1" (filter
tuning mode 1) automatically changes the machine resonance suppression filter 1
(parameter No.PB13) and notch shape selection (parameter No.PB14).
Machine resonance point
Notch frequency
Frequency
Frequency
Response of
mechanical system
Notch depth
Filter tuning mode selection
000
0000h
Setting Filter adjustment mode Automatically set parameter
0 Filter OFF (Note)
1 Filter tuning mode
Parameter No.PB13
Parameter No.PB14
2 Manual mode
Note. Parameter No.PB13 and PB14 are fixed to the initial values.
When this parameter is set to "
1", the tuning is completed after positioning is
done the predetermined number or times for the predetermined period of time, and the
setting changes to "
2". When the filter tuning is not necessary, the setting
changes to "
0". When this parameter is set to " 0", the initial values are set
to the machine resonance suppression filter 1 and notch shape selection. However, this
does not occur when the servo off.
5 - 12
5. PARAMETERS
No. Symbol Name and function
Initial
value
Unit
Setting
range
PB02 VRFT Vibration suppression control tuning mode (advanced vibration suppression control)
This parameter cannot be used in the speed control mode.
The vibration suppression is valid when the parameter No.PA08 (auto tuning) setting is
"
2" or " 3". When PA08 is " 1", vibration suppression is always
invalid.
Select the setting method for vibration suppression control tuning. Setting this parameter
to "
1" (vibration suppression control tuning mode) automatically changes the
vibration suppression control vibration frequency (parameter No.PB19) and vibration
suppression control resonance frequency (parameter No.PB20) after positioning is done
the predetermined number of times.
Droop pulse
Command
Machine end
position
Automatic
adjustment
Droop pulse
Command
Machine end
position
Vibration suppression control tuning mode
000
0000h
Setting
Vibration suppression
control tuning mode
Automatically set
parameter
0
Vibration suppression
control OFF
(Note)
1
Vibration suppression
control tuning mode
(Advanced vibration
suppression control)
Parameter No.PB19
Parameter No.PB20
2 Manual mode
Note. Parameter No.PB19 and PB20 are fixed to the initial values.
When this parameter is set to "
1", the tuning is completed after positioning is
done the predetermined number or times for the predetermined period of time, and the
setting changes to "
2". When the vibration suppression control tuning is not
necessary, the setting changes to "
0". When this parameter is set to " 0",
the initial values are set to the vibration suppression control vibration frequency and
vibration suppression control resonance frequency. However, this does not occur when
the servo off.
PB03
For manufacturer setting
Do not change this value by any means.
0
PB04 FFC Feed forward gain
This parameter cannot be used in the speed control mode.
Set the feed forward gain. When the setting is 100%, the droop pulses during operation
at constant speed are nearly zero. However, sudden acceleration/deceleration will
increase the overshoot. As a guideline, when the feed forward gain setting is 100%, set
1s or more as the acceleration/deceleration time constant up to the rated speed.
0 % 0
to
100
PB05
For manufacturer setting
Do not change this value by any means.
500
