13. SERVO AMPLIFIERS WITH A LARGE CAPACITY
(
30k TO 55kW
)
Note 1. For power supply specifications, refer to section 13.1.3.
2. Configure the circuit to turn OFF the forced stop (EM1) of the drive unit and the converter unit at the same time.
3. Always connect P
1 and P2 terminals (Factory-wired). When using the power factor improving DC reactor, refer to section 13.9.6.
4. Connect P/
and N/ terminals of the brake unit to a correct destination. Wrong connection results in the converter unit and
brake unit malfunction.
5. For the converter unit and the drive unit of 400V class, a stepdown transformer is required.
6. Contact rating: 1a contact, 110VAC_5A/220VAC_3A
Normal condition: TH1-TH2 is conducting. Abnormal condition: TH1-TH2 is not conducting.
7. Contact rating: 230VAC_0.3A/30VDC_0.3A
Normal condition: B-C is conducting/A-C is not conducting. Abnormal condition: B-C is not conducting/A-C is conducting.
8. Connect the thermal relay censor of the servo motor.
9. Do not connect more than one cable to each L
and L terminals of TE2-1 of the converter unit.
10. Always connect BUE and SD terminals (Factory-wired).
11. Connect MSG and SD terminals of the brake unit to a correct destination. Wrong connection results in the converter unit and
brake unit malfunction.
12. For connecting L
and L - terminals of TE2-1 of the converter unit to the terminal block, use the cable indicated in (3) (d) of
this section.
(c) Precautions for wiring
The cables between the converter unit and the brake unit, and between the resistor unit and the brake
unit should be as short as possible. Always twist the cable longer than 5m (twist five times or more per
one meter). Even when the cable is twisted, the cable should be less than 10m. Using cables longer
than 5m without twisting or twisted cables longer than 10m, may result in the brake unit malfunction.
Converter unit
Brake unit
5m or less 5m or less
Converter unit
Brake unit
10m or less 10m or less
P
N
P
N
P
PR PR
P
N
P
PR
P
PR
Twist
Resistor unit Resistor unit
P
N
Twist
P
(d) Cables
1) Cables for the brake unit
For the brake unit, HIV cable (600V grade heat-resistant PVC insulated wire) is recommended.
a) Main circuit terminal
N/ P/ PR
Terminal block
Brake unit
Main
circuit
terminal
screw
size
Crimping
terminal
Tightening
torque
[N
m]
Wire size
N/ , P/ , PR,
N/ , P/ ,
PR,
HIV wire
[mm
2
]
AWG
200V
class
FR-BU2-55K M6 14-6 4.4 14 6
400V FR-BU2-H55K M5 5.5-5 2.5 5.5 10
class FR-BU2-H75K M6 14-6 4.4 14 6
13 - 98
13. SERVO AMPLIFIERS WITH A LARGE CAPACITY
(
30k TO 55kW
)
b) Control circuit terminal
POINT
Under tightening can cause a cable disconnection or malfunction. Over
tightening can cause a short circuit or malfunction due to damage to the
screw or the brake unit.
A
RES
PC
B
SD
BUE
C
MSG
SD
MSG
SD SD
Jumper
Terminal block
6mm
Sheath
Core
Wire the stripped cable after twisting to prevent the cable
from becoming loose. In addition, do not solder it.
Screw size: M3
Tightening torque: 0.5N
m to 0.6N m
Wire size: 0.3mm
2
to 0.75 mm
2
Screw driver: Small flat-blade screwdriver
(Tip thickness: 0.4mm/Tip width 2.5mm)
2) Cables for connecting the servo amplifier and a distribution terminal block when connecting two sets
of the brake unit
Brake unit
Wire size
HIV wire
[mm
2
]
AWG
200V
class
FR-BU2-55K 38 2
400V FR-BU2-H55K 14 6
class FR-BU2-H75K 38 2
13 - 99
13. SERVO AMPLIFIERS WITH A LARGE CAPACITY
(
30k TO 55kW
)
(e) Crimping terminals for L
and L terminals of TE2-1 of servo amplifier
1) Recommended crimping terminals
POINT
Always use recommended crimping terminals or equivalent since some
crimping terminals cannot be installed depending on the size.
Converter unit Brake unit
Number of
connected
units
Crimping terminal (Manufacturer)
(Note 1)
Applicable
tool
200V
class
MR-J3-CR55K FR-BU2-55K 2 38-S6(Japan Solderless Terminal)
(Note 2)
R38-6S (NICHIFU) (Note 2)
a
400V MR-J3-CR55K4 FR-BU2-H55K 2 FVD14-6(Japan Solderless Terminal) b
class FR-BU2-H75K 2 38-S6(Japan Solderless Terminal)
(Note 2)
R38-6S (NICHIFU) (Note 2)
a
Note 1. Symbols in the applicable tool field indicate the following applicable tools.
Symbol
Servo amplifier side crimping terminals
Crimping
terminal
Crimping terminal
Manufacturer
Body Head Dice
a
38-S6
YPT-60-21
TD-124
TD-112
Japan Solderless
Terminal
YF-1 E-4 YET-60-1
R38-6S
NOP60
NOM60
NICHIFU
b FDV14-6 YF-1 E-4 YNE-38 DH-112 DH-122
Japan Solderless
Terminal
2. Coat the crimping part with an insulation tube.
