App. - 1
APPENDIX
App. 1 Parameter list
POINT
Parameter whose symbol is preceded by * is made valid with the following
conditions.
* : Set the parameter value, switch power off once after setting, and then
switch it on again, or perform the controller reset.
**: Set the parameter value, switch power off once, and then switch it on
again.
App. 1.1 Servo amplifier (drive unit)
Basic setting parameters (PA ) Gain/filter parameters (PB )
No. Symbol Name No. Symbol Name
PA01 For manufacturer setting PB01 FILT Adaptive tuning mode (Adaptive filter )
PA02 **REG Regenerative option
PB02 VRFT
Vibration suppression control filter tuning mode
(advanced vibration suppression control)
PA03 *ABS Absolute position detection system
PA04 *AOP1 Function selection A-1 PB03 For manufacturer setting
PA05
to
PA07
For manufacturer setting PB04 FFC Feed forward gain
PB05 For manufacturer setting
PB06 GD2
For manufacturer setting Ratio of load inertia
moment to servo motor inertia moment
PA08 ATU Auto tuning mode
PA09 RSP Auto tuning response PB07 PG1 Model loop gain
PA10 INP In-position range PB08 PG2 Position loop gain
PA11
to
PA13
For manufacturer setting PB09 VG2 Speed loop gain
PB10 VIC Speed integral compensation
PB11 VDC Speed differential compensation
PA14 *POL Rotation direction selection PB12 For manufacturer setting
PA15 *ENR Encoder output pulses PB13 NH1 Machine resonance suppression filter 1
PA16
to
PA18
For manufacturer setting PB14 NHQ1 Notch form selection 1
PB15 NH2 Machine resonance suppression filter 2
PB16 NHQ2 Notch form selection 2
PA19 *BLK Parameter write inhibit PB17 Automatic setting parameter
PB18 LPF Low-pass filter
PB19 VRF1
Vibration suppression control vibration frequency
setting
PB20 VRF2
Vibration suppression control resonance frequency
setting
PB21 For manufacturer setting
PB22
PB23 VFBF Low-pass filter selection
PB24 *MVS Slight vibration suppression control selection
PB25 For manufacturer setting
PB26 *CDP Gain changing selection
PB27 CDL Gain changing condition
PB28 CDT Gain changing time constant
PB29 GD2B
Gain changing ratio of load inertia moment to servo
motor inertia moment
PB30 PG2B Gain changing position loop gain
PB31 VG2B Gain changing speed loop gain
PB32 VICB Gain changing speed integral compensation
PB33 VRF1B
Gain changing vibration suppression control
vibration frequency setting
PB34 VRF2B
Gain changing vibration suppression control
resonance frequency setting
PB35
to
PB45
For manufacturer setting
App. - 2
A
PPENDI
X
Extension setting parameters (PC ) I/O setting parameters (PD )
No. Symbol Name No. Symbol Name
PC01 *ERZ Error excessive alarm level PD01
to
PD06
For manufacturer setting
PC02 MBR Electromagnetic brake sequence output
PC03 *ENRS Encoder output pulses selection
PC04 **COP1 Function selection C-1 PD07 *DO1 Output signal device selection 1 (CN3-13)
PC05 **COP2 Function selection C-2 PD08 *DO2 Output signal device selection 2 (CN3-9)
PC06 *COP3 Function selection C-3 PD09 *DO3 Output signal device selection 3 (CN3-15)
PC07 ZSP Zero speed PD10
to
PD13
For manufacturer setting
PC08 For manufacturer setting
PC09 MOD1 Analog monitor 1 output
PC10 MOD2 Analog monitor 2 output PD14 *DOP3 Function selection D-3
PC11 MO1 Analog monitor 1 offset PD15
to
PD32
For manufacturer setting
PC12 MO2 Analog monitor 2 offset
PC13 MOSDL Analog monitor feedback position output
standard data Low
PC14 MOSDH Analog monitor feedback position output
standard data High
PC15
to
PC16
For manufacturer setting
PC17 **COP4 Function selection C-4
PC18
to
PC20
For manufacturer setting
PC21 *BPS Alarm history clear
PC22
to
PC32
For manufacturer setting
App. 1.2 Converter unit
No. Symbol Name
PA01 *REG Regenerative selection
PA02 *MCC Magnetic contactor drive output selection
PA03
to
PA07
For manufacturer setting
PA08 *DMD Status display selection
PA09 *BPS Alarm history clear
PA10 For manufacturer setting
PA11
PA12 *DIF Input filter setting
PA13
to
PA19
For manufacture setting
