13 - 15
13. SERVO AMPLIFIERS WITH A LARGE CAPACITY
(
30k TO 55kW
)
(2) MR-J3-DU30KB4 or MR-J3-DU37KB4
(a) Upper terminal block cover
1) How to open
A
)
A)'
Pull up the cover using the axis A), A)' as a
support.
When pulled up to the top, the cover is fixed.
13 - 16
13. SERVO AMPLIFIERS WITH A LARGE CAPACITY
(
30k TO 55kW
)
2) How to close
Setting tab
A)
A)'
Close the cover using the axis A), A)' as a
support.
Setting tab
Press the cover against the terminal box until
the installing knobs click.
13 - 17
13. SERVO AMPLIFIERS WITH A LARGE CAPACITY
(
30k TO 55kW
)
(b) Lower terminal block cover
1) How to open
Hold the bottom of the terminal block cover
with both hands.
B)
B)'
Pull up the cover using the axis B), B)' as a
support.
When pulled up to the top, the cover is fixed.
