NPM–W 2 EJM7DE-MB-02 -1T-00 Stamp Parts Drop Error Stamp Time Over Error Stamp Empty Error Nozzle Error Rate Stop Error Message Troubleshooting 2-1-3 Single stop er r or 16 Error Code Error Message Cause Inspection and S…
NPM–W2 EJM7DE-MB-02-1T-00
Head Error Rate Stop
Feeder Error Rate Stop
No Feeder Cover
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Operation was attempted
without attaching the feeder
cover.
(Single stop error occurred.)
Take any of the following measures:
1) Attach the feeder cover.
2) If the error persists even after the
feeder cover is attached, the
connection with the connector of
the feeder cover may not be
detected. Choose [Machine] -
[Adjust] - [All] - [Input confirm] and
check the connection of the feeder
cover.
40393
Pickup errors and/or
recognition errors have
occurred beyond the bad
feeder error rate set in action
parameters.
(Single stop error occurred.)
Check the condition of the feeder
and clean it if necessary.
40394
Pickup errors and/or
recognition errors have
occurred beyond the bad
head error rate set in action
parameters.
(Single stop error occurred.)
Check the condition of the head and
clean it if necessary.
40395
2-1-3-29
NPM–W2 EJM7DE-MB-02-1T-00
Stamp Parts Drop Error
Stamp Time Over Error
Stamp Empty Error
Nozzle Error Rate Stop
Error
Message
Troubleshooting
2-1-3
Single stop error 16
Error Code
Error Message
Cause Inspection and Solution
Pickup errors and/or
recognition errors have
occurred beyond the bad
nozzle error rate set in action
parameters.
(Single stop error occurred.)
Check the condition of the nozzle
and clean it if necessary.
40396
Transcript material has run
out.
(Single stop error occurred.)
Supply the transcript material.
40397
Transcript time was
exceeded.
(Single stop error occurred.)
Supply the transcript material.
40398
Component may have
dropped in the transcript unit.
(Single stop error occurred.)
Check the transcript unit and
remove any component.
40399
2-1-3-30
NPM–W2 EJM7DE-MB-02-1T-00
Threshold set err
(VLC)
Comm. status err
(VLC)
Sensor abnormality
(VLC)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Camera is blocked entirely
or partly.
2) Optical axis is displaced.
3) Failure of vertical line
camera detected.
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Since the sensor is blocked,
remove any foreign body. Wipe
away any dirt from the lens if it is
dirty. If there is no foreign body,
check the connection of connector.
2) Adjust the optical axis of the
sensor.
3) Check the situation of the error
occurred and error message, and
contact PFSC.
40400
Communication status error
detected in issuing command.
(Single stop error occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
40401
Nozzle height offset is
beyond the threshold value.
Pre-scanning setting of the
vertical line camera could not
be made.
(Single stop error occurred.)
The offset value of the nozzle height
detection is not correct. Calibrate
the origin offset Z-axis and vertical
line camera.
40402
2-1-3-31
