NPM–W2 EJM7DE-MB-02-1T-00
Parts Recognition Error
Parts Recognition Error
Error
Message
Troubleshooting
2-1-3
Single stop error 27
Error Code
Error Message
Cause Inspection and Solution
Error occurred in the internal
parameter required for image
taking.
(Parameter-related error in
loading recognition error
image)
Take any of the following measures:
1) Check the connection of
camera/sensor and lighting
units.Connected units can be
checked on the unit information
check screen.
2) Send the recognition data and
image detail data to PFSC.
43009
Mismatch occurred in the
parameter used in the
internal processing of
recognition.
(Recognition error - Invalid
image processing
parameter )
Take any of the following measures:
1) Check the connection of
camera/sensor and lighting
units.Connected units can be
checked on the unit information
check screen.
2) Send the recognition data and
image detail data to PFSC.
43010
2-1-3-52
NPM–W2 EJM7DE-MB-02-1T-00
Parts Recognition Error
Parts Recognition Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Error in the combination of
shape data in recognition
data.
- Several electrodes
arranged in one position.
- Shape data set more than
the limit.
2) Shape or combination of
shapes not supported by
the current version of the
recognition system in use
has been specified.
- Unsupported shape data or
recognition option data has
been specified.
(Recognition error -
Combination of shape data)
Take any of the following measures:
1) Check the number of registered
shapes and check for multiple
shapes assigned to the same
mounting location.
2) Check the version of the
recognition system.
3) Send the recognition data and
image detail data to PFSC.
43011
Any of the following causes
is likely:
1) Error in the combination of
shape data in recognition
data.
- Several electrodes
arranged in one position.
- Shape data set more than
the limit.
2) Shape or combination of
shapes not supported by
the current version of the
recognition system in use
has been specified.
- Unsupported shape data or
recognition option data has
been specified.
(Recognition error -
Unsupported component
shape)
Take any of the following measures:
1) Check the number of registered
shapes and check for multiple
shapes assigned to the same
mounting location.
2) Check the version of the
recognition system.
3) Send the recognition data and
image detail data to PFSC.
43012
2-1-3-53
NPM–W2 EJM7DE-MB-02-1T-00
Error
Message
Troubleshooting
2-1-3
Single stop error 28
Error Code
Error Message
Cause Inspection and Solution
2-1-3-54
Recognition
result
Description
Recognition
result
Description
Ans13（0）
Option data specified parameter
error
Ans13（22）
Electrode width/diameter
parameter error
Ans13（1）
Target shape kind parameter
error
Ans13（23）
Allowable electrode pitch
parameter error
Ans13（2）
Recognition mode parameter
error
Ans13（24）
Electrode width/allowable
diameter parameter error
Ans13（3）
Defective judgment limit
parameter error
Ans13（25）
Allowable raised electrode
parameter error
■ Values and descriptions of the recognition result Ans13()
Parts Recognition Error
1) Error in the specified
recognition data
- Shape data set more than
the limit.
- Multiple shape information
arranged in one position.
- Improper specified
electrode count in lead
group or ball group- Array
length in lead group or ball
group is beyond component
outer shape size.The
following parameter errors
will result according to
recognition result answers.
2) Error in the combination of
specified recognition data.
- Several electrodes in
different shapes arranged
in one position.
(Recognition error -
Specified recognition
parameter)
Check the specified recognition data
corresponding to the recognition
result answer.
43013
