NPM–W 2 EJM7DE-MB-02 -1T-00 Parts Re cognition Error Solutions to errors Error Code Error Message Cause Inspection and Solution Detected comp onent size in W (Y) direction is invalid.Component size in W direction differs…

NPM–W2 EJM7DE-MB-02-1T-00

Parts Recognition Error

Error

Message

Troubleshooting

2-1-3

Single stop error 33

Error Code

Error Message

Cause Inspection and Solution

Detected component size in

L (X) direction is

invalid.Component size in L

direction differs widely from

registered data.

(Recognition error -

Measurement result in size L

direction)

Take any of the following measures:

1) Check the component outer

shape size and the distance of

shapes in L (X) direction.For

components with electrodes at

both sides, check the distance

between the electrodes.In case of

a recognition error of Ans25

(30~39), an error is detected when

performing detailed check of the

component size.If the component

size varies widely and variation

can be tolerated with actual

components, specify the

Recognition option: Component

size limit.

2) Check the image status of the

component at both sides.If the

shape of the ends like J-lead

component or curved component

is unclear on the image, adjust the

lamp value and correct the image

status.(At this time, the side

lighting is effective.)

3) Check the component pickup

position and pickup

condition.Make sure the

component pickup position is not

placed at the center and the

component is not likely to be in the

slanted pickup posture.

43025

2-1-3-64

NPM–W2 EJM7DE-MB-02-1T-00

Parts Recognition Error

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Detected component size in

W (Y) direction is

invalid.Component size in W

direction differs widely from

registered data.

(Recognition error -

Measurement result in size

W direction)

Take any of the following measures:

1) Check the component outer

shape size and the distance of

shapes in W (Y) direction.For

components with electrodes at

both sides, check the distance

between the electrodes.In case of

a recognition error of Ans26

(30~39), an error is detected when

performing detailed check of the

component size.If the component

size varies widely and variation

can be tolerated with actual

components, specify the

Recognition option: Component

size limit.

2) Check the image status of the

component at both sides.If the

shape of the ends like J-lead

component or curved component

is unclear on the image, adjust the

lamp value and correct the image

status.(At this time, the side

lighting is effective.)

3) Check the component pickup

position and pickup

condition.Make sure the

component pickup position is not

placed at the center and the

component is not likely to be in the

slanted pickup posture.

43026

2-1-3-65

NPM–W2 EJM7DE-MB-02-1T-00

Parts Recognition Error

Error

Message

Troubleshooting

2-1-3

Single stop error 34

Error Code

Error Message

Cause Inspection and Solution

No characteristic in shape

that matches registered

component size L/W

detected.

(Recognition error -

Measurement result in size L

or W direction)

Take any of the following measures:

1) Check the component outer

shape size and the distance of

shapes in L (X) / W (Y)

direction.For components with

electrodes at both sides, check the

distance between the electrodes or

width.

2) Check the image status of the

component at both sides.If the

shape of the ends like J-lead

component or curved component

is unclear on the image, adjust the

lamp value and correct the image

status.(At this time, the side

lighting is effective.)

3) Check the component pickup

position and pickup

condition.Make sure the

component pickup position is not

placed at the center and the

component is not likely to be in the

slanted pickup posture.

43027

2-1-3-66
