NPM–W 2 EJM7DE-MB-02 -1T-00 P9Case Temp erature Error P9Case Fan Error P9 Power Fan Error Solutions to errors Error Code Error Message Cause Inspection and Solution Fan of the P9 controller power stopped. (Self-di agnosi…
NPM–W2 EJM7DE-MB-02-1T-00
Tray A Control Board Fuse
Disconnection
Tray A Control Board
Temperature Error
Tray A Control Board
Voltage Error
L-Camera Board External
24V Fuse Disconnection
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 14
Error Code
Error Message
Cause Inspection and Solution
External 24V fuse of the line
camera light control board
has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40085
Voltage at the tray control
board has dropped
abnormally.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40086
CPU temperature at the tray
control board has exceeded
the setting value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40087
Fuse of the tray control board
has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40088
2-1-2-27
NPM–W2 EJM7DE-MB-02-1T-00
P9Case Temperature
Error
P9Case Fan Error
P9 Power Fan Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Fan of the P9 controller
power stopped.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Check the fan for any
interference with wiring, etc.
2) Make sure there is no
disconnected wire.
40089
Fan of the P9 controller case
stopped.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Check the fan for any
interference with wiring, etc.
2) Make sure there is no
disconnected wire.
40090
Inside temperature of the P9
controller case is higher than
the setting value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40091
2-1-2-28
NPM–W2 EJM7DE-MB-02-1T-00
Y Axis Servo Amp Fan
Error
X Axis Servo Amp Fan
Error
Servo Amp External Fan
Error
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 15
Error Code
Error Message
Cause Inspection and Solution
External fan of the XY servo
amplifier stopped.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1)Check the fan for any interference
with wiring, etc.
2) Make sure there is no
disconnected wire.
40092
Fan of the X-axis servo
amplifier stopped
(Self-diagnosis error
occurred.)
Take any of the following measures:
1)Check the fan for any interference
with wiring, etc.
2) Make sure there is no
disconnected wire.
40093
Fan of the Y-axis servo
amplifier stopped
(Self-diagnosis error
occurred.)
Take any of the following measures:
1)Check the fan for any interference
with wiring, etc.
2) Make sure there is no
disconnected wire.
40094
2-1-2-29
