NPM–W 2 EJM7DE-MB-02 -1T-00 Head Move Error Cancel Flag Error Post Proc Adjacent Safety Device Error Error Message Troubleshooting 2-1-2 Self-dia gnosis er r or s 17 Error Code Error Message Cause Inspection and Solution…
NPM–W2 EJM7DE-MB-02-1T-00
Pre Proc Adjacent Safety
Device Error
There is no feeder cover
or tray feeder
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
No feeder cover. Or tray
feeder not installed.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Attach the feeder cover when the
feeder cart is used.
2) When the tray feeder is used,
install the tray feeder and then
insert the key in the tray feeder
detection switch.
3) If the error persists, choose
[Machine] - [Adjust] - [All] - [Input
confirm] and check that the feeder
cover is attached and the tray
detection switch is connected.
40100
Any of the following causes
is likely:
1) Foreign body found at the
transfer opening.
2) Feeder cover not attached.
3) Emergency stop switch of
the adjoining machine has
been pressed.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Remove any foreign body from
the transfer opening.
2) Attach the feeder cover.
3) Reset the emergency stop status
of the adjoining machine.
40101
2-1-2-32
NPM–W2 EJM7DE-MB-02-1T-00
Head Move Error
Cancel Flag Error
Post Proc Adjacent Safety
Device Error
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 17
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Foreign body found at the
transfer opening.
2) Feeder cover not attached.
3) Emergency stop switch of
the adjoining machine has
been pressed
(Self-diagnosis error
occurred.)
Take any of the following measures:
1) Remove any foreign body from
the transfer opening.
2) Attach the feeder cover.
3) Reset the emergency stop status
of the adjoining machine.
40102
Any of the following causes
is likely:
1) Cover switch is disabled.
2) Only the feeder cover
connector
connected/disconnected
without opening/closing the
cover.
(Self-diagnosis error
occurred.)
Take any of the following
measures:Open/close the cover and
restart the machine.If the trouble
persists even after the above steps,
the cover switch may be
broken.Contact PFSC.
40103
Head may interfere with the
mounted components on the
board.
(Self-diagnosis error
occurred.)
Move the head to the pickup position
by hand. In doing so, take care not
to interfere with the mounted
components
40104
2-1-2-33
NPM–W2 EJM7DE-MB-02-1T-00
LNB Production Start Error
LNB Communication
Abnormality
Chip Thickness Sensor
Unmatched Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Mismatch between the frame
and chip thickness sensor
(Self-diagnosis error
occurred.)
Make sure the chip thickness sensor
that matches the frame is installed.
40105
Communication disabled due
to broken wires in the
communication system or
trouble like hub power OFF
(Self-diagnosis error
occurred.)
Check the communication system
and the power to the hub is
ON.When the simplified LNB is
used, check if the power to the
simplified LNB computer is ON. To
restart the LNB conveyor or
simplified LNB computer when the
machine is running, engage all the
machines in the cycle stop mode or
restart the machine from the main
menu.
40106
Machine is not ready for
production with the PanaCIM
or customer's system.
(Self-diagnosis error
occurred.)
Enable production with the PanaCIM
or customer's system.
40107
2-1-2-34
