NPM–W 2 EJM7DE-MB-02 -1T-00 Shape of Parts e rr (VLC) Part Thick range ov (VLC) Part Thick det err (VLC) Solutions to errors Error Code Error Message Cause Inspection and Solution Any of the following causes is likely: 1…

NPM–W2 EJM7DE-MB-02-1T-00

Nzl Point Abnormal Error

Nzl Height Range Ov

(VLC)

Nzl Height Det Err

(VLC)

Error

Message

Troubleshooting

2-1-3

Single stop error 17

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Measured nozzles and

measurement result

nozzles do not agree.

2) Measurement result is out

of output value.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Check the mounting condition of

the nozzle.

2) Make sure that there is no foreign

body on the lens of the vertical line

camera and diagonal line on the

emitter and detector sides of the

laser. Calibrate the origin offset Z-

axis and vertical line camera.

40403

Any of the following causes

is likely:

1) Difference between nozzle

detection result and nozzle

length exceeded ±0.050

mm.

2) Nozzle recognition height

and optical axis of the

vertical line camera are

displaced.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Check the nozzle length.

2) Calibrate the origin offset Z-axis

and vertical line camera.

40404

Tip of the nozzle is not planar.

(Single stop error occurred.)

Check the tip of the nozzle and

clean it. Replace the faulty nozzle.

40405

2-1-3-32

NPM–W2 EJM7DE-MB-02-1T-00

Shape of Parts err

(VLC)

Part Thick range ov

(VLC)

Part Thick det err

(VLC)

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Measured nozzles and

measurement result

nozzles do not agree.

Scanning status of

measured component

affects the scan of other

nozzles.

2) Measurement result is out

of effective range of output

value of the vertical line

camera.

(Single stop error occurred.)

Make sure the component is set

properly and correct values of the

component data (component

dimensions, etc.) are set.

40406

Component thickness

measurement result is

beyond the threshold value of

thickness tolerance.

(Single stop error occurred.)

Check the upper and lower limits of

the thickness tolerance in the

mounting condition data of

component data.

40407

Invalid component pickup

status.

(Single stop error occurred.)

Check the component data

(component dimensions, etc.).Check

the pickup condition.

40408

2-1-3-33

NPM–W2 EJM7DE-MB-02-1T-00

Feeder Pull-out error

Servo Switch Off

Pick up error

(VLC)

Error

Message

Troubleshooting

2-1-3

Single stop error 18

Error Code

Error Message

Cause Inspection and Solution

Any of the following causes

is likely:

1) Incorrect component data

height

2) Improper component feed.

3) Incorrect feeder position.

(Single stop error occurred.)

Take measures shown with the

same number as that of the cause.

1) Correct the component data.

2) Replace the tape feeder.

3) Choose [Production data] -

[Teach] - [Feeder] - [Pickup

position] and perform teaching of

the component pickup position.

40409

Servo switch turned OFF.

(Single stop error occurred.)

Take measures in the following

order.

1) Turn the servo switch clockwise

to turn it ON. (One position each at

front and rear)

2) If the error persists even after the

servo switch is tuned ON, the

switch may be broken.Contact

PFSC.

40410

Feeder was pulled out due to

a reason other than

component empty.

(Single stop error occurred.)

Set the feeder again.

40411

2-1-3-34
