NPM–W 2 EJM7DE-MB-02 -1T-00 Operation Switch Board Temper ature Erro r Fan Error Under Base Ceiling Fan Error Solutions to errors Error Code Error Message Cause Inspection and Solution Ceiling fan stopped. (Self-di agnos…
NPM–W2 EJM7DE-MB-02-1T-00
Y Axis Servo Amp Fan
Error
X Axis Servo Amp Fan
Error
Servo Amp External Fan
Error
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 15
Error Code
Error Message
Cause Inspection and Solution
External fan of the XY servo
amplifier stopped.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1)Check the fan for any interference
with wiring, etc.
2) Make sure there is no
disconnected wire.
40092
Fan of the X-axis servo
amplifier stopped
(Self-diagnosis error
occurred.)
Take any of the following measures:
1)Check the fan for any interference
with wiring, etc.
2) Make sure there is no
disconnected wire.
40093
Fan of the Y-axis servo
amplifier stopped
(Self-diagnosis error
occurred.)
Take any of the following measures:
1)Check the fan for any interference
with wiring, etc.
2) Make sure there is no
disconnected wire.
40094
2-1-2-29
NPM–W2 EJM7DE-MB-02-1T-00
Operation Switch Board
Temperature Error
Fan Error Under Base
Ceiling Fan Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Ceiling fan stopped.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1)Check the fan for any interference
with wiring, etc.
2) Make sure there is no
disconnected wire.
40095
Fan under the base stopped.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1)Check the fan for any interference
with wiring, etc.
2) Make sure there is no
disconnected wire.
40096
CPU temperature at the
operation switch board has
exceeded the setting value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40097
2-1-2-30
NPM–W2 EJM7DE-MB-02-1T-00
No Changer unit
No Eject BOX
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 16
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Component ejection box
not set in position.
2) Nozzle wiping station
(only for dispense head)
has been set.
(Self-diagnosis error
occurred.)
Reset the component ejection box
properly.
40098
Nozzle changer not installed.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Install the changer corresponding
to the head.
2) If the error persists even after the
changer is installed, the
connection with the changer may
not be detected.Choose [Machine]
- [Adjust] - [All] - [Input confirm]
and check the connection of
changer.
40099
2-1-2-31
