NPM–W2 EJM7DE-MB-02-1T-00
Unknown Unit Detection
(Parts recognition camera)
Unknown Unit Detection
(Head)
Installed Head Non-
support Unit
(Tray)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Tray cannot be used with the
installed head.
(Self-diagnosis error
occurred.)
Replace the head with the one that
can use the tray.
40040
Head cannot be detected.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Make sure the head is set
properly.
2) Choose [Machine] - [Information]
- [PnP] - [List] and make sure the
head is installed. If the error
persists, contact PFSC.
40041
Parts recognition camera
cannot be detected.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Make sure the parts recognition
camera is set properly.
2) Choose [Machine] - [Information]
- [PnP] - [List] and make sure the
parts recognition camera is
installed. If the error persists,
contact PFSC.
40042
2-1-2-16
NPM–W2 EJM7DE-MB-02-1T-00
Unknown Unit Detection
(Supply section)
Unknown Unit Detection
(3D)
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 9
Error Code
Error Message
Cause Inspection and Solution
3D sensor cannot be
detected.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Make sure the 3D sensor is set
properly.
2) Choose [Machine] - [Information]
- [PnP] - [List] and make sure the
3D sensor is installed. If the error
persists, contact PFSC.
40043
Feeder unit cannot be
detected.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Make sure the unit is set properly
to the feeder carriage.
2) Choose [Machine] - [Information]
- [PnP] - [List] and make sure the
unit is installed to the feeder. If the
error persists, contact PFSC.
40044
2-1-2-17
NPM–W2 EJM7DE-MB-02-1T-00
Unknown Unit Detection
(Chip thickness sensor)
Unknown Unit Detection
(Changer)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Changer cannot be detected.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Make sure the changer is set
properly to the feeder carriage.
2) Choose [Machine] - [Information]
- [PnP] - [List] and make sure the
unit is installed to the changer. If
the error persists, contact PFSC.
40045
Chip thickness sensor
cannot be detected.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Make sure the chip thickness
sensor is set properly.
2) Choose [Machine] - [Information]
- [PnP] - [List] and make sure the
unit is installed to the chip
thickness sensor. If the error
persists, contact PFSC.
40046
2-1-2-18
