NPM–W2 EJM7DE-MB-02-1T-00
Servo Amplifier
Abnormality
(Rear X axis)
Servo Amplifier
Abnormality
(Front Y axis)
Servo Amplifier
Abnormality
(Front X axis)
Nozzle Interference Area
Intrusion
(Rear Side Rear Row)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
8
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Z-axis interference sensor
may be at fault or sensor
cable may be broken.
2) Y-axis interference sensor
may be at fault or sensor
cable may be broken.
(Interlock occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and if any problem is
found, contact PFSC.
1327
Servo driver is at fault.
(Interlock occurred.)
1) Make sure there is no obstacle to
the X/Y axes and restart the
machine.
2) If the error persists, contact
PFSC.
1328
Servo driver is at fault.
(Interlock occurred.)
1) Make sure there is no obstacle to
the X/Y axes and restart the
machine.
2) If the error persists, contact
PFSC.
1329
Servo driver is at fault.
(Interlock occurred.)
1) Make sure there is no obstacle to
the X/Y axes and restart the
machine.
2) If the error persists, contact
PFSC.
1330
2-1-4-15
NPM–W2 EJM7DE-MB-02-1T-00
AMP Detect AC_FAIL
Error
Y Axis Interference
Servo Amplifier
Abnormality
(Rear Y axis)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Servo driver is at fault.
(Interlock occurred.)
1) Make sure there is no obstacle to
the X/Y axes and restart the
machine.
2) If the error persists, contact
PFSC.
1331
Front X/Y axes and rear X/Y
axes interfered with each
other.
(Interlock occurred.)
Separate them from the opposite
X/Y axes.
1332
Power supply may have
been stopped momentarily
due to power failure.
(Instantaneous power failure
occurred due to power
voltage of servo amplifier)
Check the voltage of the power
supply in the plant. Return to the
main menu and restart production. If
the error persists, contact PFSC.
1333
2-1-4-16
NPM–W2 EJM7DE-MB-02-1T-00
Tape cover detection1
(Front)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
9
Error Code
Error Message
Cause Inspection and Solution
Tape cover sensor 1 is
blocked.
(Interlock occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the top tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 1 of the
table is OFF when the light from
the emitter is blocked and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
1334
2-1-4-17
