NPM-W 2 EJM7DE-MB-04T-00 4-2-2 -3 Unit name N o. Name Location Remark 12-nozzle hea d R3001 Va c u u m v a l v e 1 R3002 Va c u u m v a l v e 2 R3003 Va c u u m v a l v e 3 R3004 Va c u u m v a l v e 4 R3005 Va c u u m v…
NPM-W2 EJM7DE-MB-04T-00
4-2-2-2
Unit name No. Name
Location Remark
16-nozzle head R3001 Vacuum valve 1
R3002 Vacuum valve 2
R3003 Vacuum valve 3
R3004 Vacuum valve 4
R3005 Vacuum valve 5
R3006 Vacuum valve 6
R3007 Vacuum valve 7
R3008 Vacuum valve 8
R3009 Vacuum valve 9
R3010 Vacuum valve 10
R3011 Vacuum valve 11
R3012 Vacuum valve 12
R3013 Vacuum valve 13
R3014 Vacuum valve 14
R3015 Vacuum valve 15
R3016 Vacuum valve 16
R3021 Blow valve 1
R3022 Blow valve 2
R3023 Blow valve 3
R3024 Blow valve 4
R3035 Blow valve 5
R3026 Blow valve 6
R3027 Blow valve 7
R3928 Blow valve 8
R3029 Blow valve 9
R3030 Blow valve 10
R3031 Blow valve 11
R3032 Blow valve 12
R3033 Blow valve 13
R4034 Blow valve 14
R3035 Blow valve 15
R3036 Blow valve 16
Option
Load arrangement
drawings
NPM-W2 EJM7DE-MB-04T-00
4-2-2-3
Unit name No. Name
Location Remark
12-nozzle head R3001
Vacuum valve 1
R3002
Vacuum valve 2
R3003
Vacuum valve 3
R3004
Vacuum valve 4
R3005
Vacuum valve 5
R3006
Vacuum valve 6
R3007
Vacuum valve 7
R3008
Vacuum valve 8
R3009
Vacuum valve 9
R3010
Vacuum valve 10
R3011
Vacuum valve 11
R3012
Vacuum valve 12
R3013
Blow valve 1
R3014
Blow valve 2
R3015
Blow valve 3
R3016
Blow valve 4
R3017
Blow valve 5
R3018
Blow valve 6
R3019
Blow valve 7
R3020
Blow valve 8
R3021
Blow valve 9
R3022
Blow valve 10
R3023
Blow valve 11
R3024
Blow valve 12
Option
Load lists
Solenoid list 2
Troubleshooting
4-2-2
NPM-W2 EJM7DE-MB-04T-00
4-2-2-4
Unit name No. Name
Location Remark
8-nozzle head R3001
Vacuum valve 1
R3002
Vacuum valve 2
R3003
Vacuum valve 3
R3004
Vacuum valve 4
R3005
Vacuum valve 5
R3006
Vacuum valve 6
R3007
Vacuum valve 7
R3008
Vacuum valve 8
R3013
Blow valve 1
R3014
Blow valve 2
R3015
Blow valve 3
R3016
Blow valve 4
R3017
Blow valve 5
R3018
Blow valve 6
R3019
Blow valve 7
R3020
Blow valve 8
3-nozzle head R3001
Vacuum valve 1
R3002
Vacuum valve 2
R3003 Vacuum valve 3
R3013
Blow valve 1
R3014
Blow valve 2
R3015 Blow valve 3
Dispensing head R3001 Air 1
R3002 Air 2
Single tray feeder
main body
R3310
Magazine shutter open
R3311
Replenishment-section shutter close
R3316
Magazine door lock close
R3317
Magazine door lock open
Twin tray feeder main
body
R3310
Magazine shutter open (A)
R3311
Replenishment-section shutter close (A)
R3316
Magazine door lock close (A)
R3317
Magazine door lock open (A)
R3610
Magazine shutter open (B)
R3611
Replenishment-section shutter close (B)
R3616
Magazine door lock close (B)
R3617
Magazine door lock open (B)
Multifunctional transfer
unit
R301 Auto-supply valve
Load arrangement
drawings
