NPM–W 2 EJM7DE-MB-02 -1T-00 Feeder Mainte Cnt Over PCB Bar Code Recog Err Solutions to errors Error Code Error Message Cause Inspection and Solution Any of the following causes is likely: 1) R ecognition mark is out of c…
NPM–W2 EJM7DE-MB-02-1T-00
Nozzle Missing
(Rack)
Unnecessary Nzl
(Rack)
Cart Offset Recog Err
Cart Offset Range over
Clogged Nozzle Detect
Error
Message
Troubleshooting
2-1-3
Single stop error 14
Error Code
Error Message
Cause Inspection and Solution
Clogged nozzle detected.
(Single stop error occurred.)
Clean the applicable nozzle.
40383
Recognition result of cart
offset mark is beyond the
specified range.
(Single stop error occurred.)
Make sure the feeder cart is set to
the machine in the upright position.
If slanted, detach the feeder cart
once and attach it again.
40384
Failed to recognize the cart
offset mark.
(Single stop error occurred.)
Make sure the cart offset mark is
free of dirt or dust.
40385
A nozzle was detected on a
head where it should not
have been^ in nozzle check
processing of the head unit.
(Single stop error occurred.)
Remove the applicable nozzle from
the head.
40386
A nozzle was not detected
on a head where it should
have been^ in nozzle check
processing of the head unit.
(Single stop error occurred.)
Choose [Machine] - [Adjust] - [Head]
- [Nozzle exchange] and match the
mounting condition of the actual
nozzle and memory on the machine.
40387
2-1-3-26
NPM–W2 EJM7DE-MB-02-1T-00
Feeder Mainte Cnt Over
PCB Bar Code Recog Err
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Recognition mark is out of
camera's view.
2) Recognition error
occurred due to dirt on PCB.
3) Incorrect PCB barcode
recognition coordinates
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Using the inching function, move
the camera to the recognition mark
position and press the [Re-
recognize] button.
2) After cleaning the recognition
camera and PCB, press the [Re-
recognize] button. If the
recognition error occurs again,
move the camera to the
recognition mark position with the
[Pass] button or inching function
and press the [Manual set] button.
[Pass]: Pass the PCB.[Manual
set]: Save the inching amount as
the offset.
3) Choose [Production data] -
[Correct] - [PCB] - [PCB recog.]
and enter the correct PCB
recognition coordinates.
40388
Machine stopped because
the pickup count of the
feeder is beyond the
maintenance count.
(Single stop error occurred.)
Choose [Maintenance] - [Regular
inspection] (feeder maintenance) to
confirm the feeders concerned and
perform maintenance for them.
40389
2-1-3-27
NPM–W2 EJM7DE-MB-02-1T-00
Pst Prc Adjcnt Safe Unit
Err
Pre Prc Adjcnt Safe Unit
Err
Regular Check Error
Error
Message
Troubleshooting
2-1-3
Single stop error 15
Error Code
Error Message
Cause Inspection and Solution
Component information
written into feeder memory
for regular check and
scanned reel barcode
information not matched.
(Single stop error occurred.)
Read the correct reel barcode.
40390
1) Foreign body found at the
transfer opening.
2) Feeder cover not attached.
3) Emergency stop switch of
the adjoining machine has
been pressed.
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Remove any foreign body from
the transfer opening.
2) Attach the feeder cover.
3) Release the emergency stop
status of the adjoining machine.
40391
1) Foreign body found at the
transfer opening.
2)Feeder cover not attached.
3) Emergency stop switch of
the adjoining machine has
been pressed.
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Remove any foreign body from
the transfer opening.
2) Attach the feeder cover.
3)Release the emergency stop
status of the adjoining machine.
40392
