NPM–W 2 EJM7DE-MB-02 -1T-00 Nzl Point Abno rmal Error Nzl Hei ght Range Ov (Rec og.) Nzl Height Det Err (Rec og.) Tape unset error Tape off detect error Error Message Troubleshooting 2-1-3 Single stop er r or 23 Error Co…
NPM–W2 EJM7DE-MB-02-1T-00
Pick up error
(Recog.)
Shape of Parts err
(Recog.)
Part Thick range ov
(Recog.)
Part Thick det err
(Recog.)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Messure result is out of
effective range.
(Single stop error occurred.)
Make sure the component is set
properly and correct values of the
component data (component
dimensions, etc.) are set.
40452
Component thickness
measurement result is
beyond the threshold value of
thickness tolerance.
(Single stop error occurred.)
Check the upper and lower limits of
the thickness tolerance in the
mounting condition data of
component data.
40453
Invalid component pickup
status.
(Single stop error occurred.)
Check the component data
(component dimensions, etc.).Check
the pickup condition.
40454
Any of the following causes
is likely:
1) Incorrect component data
height
2) Improper component feed.
3) Incorrect feeder position.
(Single stop error occurred.)
Take measures shown with the
same number as that of the cause.
1) Correct the component data.
2) Replace the tape feeder.
3) Choose [Production data] -
[Teach] - [Feeder] - [Pickup
position] and perform teaching of
the component pickup position.
40455
2-1-3-43
NPM–W2 EJM7DE-MB-02-1T-00
Nzl Point Abnormal Error
Nzl Height Range Ov
(Recog.)
Nzl Height Det Err
(Recog.)
Tape unset error
Tape off detect error
Error
Message
Troubleshooting
2-1-3
Single stop error 23
Error Code
Error Message
Cause Inspection and Solution
The tape may be dropped out.
(Single stop error occurred.)
Check if the tape is inserted
correctly.
40456
The tape is not set.
(Single stop error occurred.)
Check if the tape is inserted
correctly.
40457
Measurement result is out of
output value.
(Single stop error occurred.)
Check the mounting status of the
nozzle.Make sure that there is no
foreign body on the lens of the parts
recognition camera.Calibrate origin
offset Z-axis and multi recognition
camera offset.
40458
Difference between nozzle
detection result and nozzle
length exceeded the range of
-0.3mm~0.4mm.
(Single stop error occurred.)
Check the nozzle length.Calibrate
origin offset Z-axis and multi
recognition camera offset.
40459
Tip of the nozzle is not planar.
(Single stop error occurred.)
Check the tip of the nozzle and
clean it. Replace the faulty nozzle.
40460
2-1-3-44
NPM–W2 EJM7DE-MB-02-1T-00
No recognition nozzle
error
Tape change action
incomplete
Pattern data error
Part Recog Err
(check drop)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Error happened at the drop
detect before ejecting of the
parts recognition error or
pickup error.
(Recognition error Drop
detect before ejecting)
Please confirm that if there are parts
dropped on the PCB after finishing
the auto running and remove the
PCB.
40463
It is not possible to read the
recognition pattern data of
block match teach or
asymmetric array BGA
teach.Any of the following
causes is likely.
1) Device is not connected.
2) Recognition pattern data
is inexistent.
(Single stop error occurred.)
1) Please confirm the connect state
of LNB or SD card.
2) Please execute block match
teach or asymmetric array BGA
teach.
40464
Failed in tape change action.
(Single stop error occurred.)
Please set the new tape again from
the beginning.
40465
In nozzle confirm
processing^ it is detected
that the necessary nozzle for
recognition isn't arranged in
stocker.
(Single stop error occurred.)
Please set the nozzle to applicable
stocker.
40466
