NPM–W 2 EJM7DE-MB-02 -1T-00 Timer safety relay abnormal R mo veable cover open or close action incomplete error F moveable cover open or close action incomplete error R car t unconnected error Solutions to errors Error C…
NPM–W2 EJM7DE-MB-02-1T-00
F cart unconnected error
Moveable cover open error
Nzl Direction Setting Error
Tray Pos Offset Measure
Err
LNB nzl use interlock error
Error
Message
Troubleshooting
2-1-3
Single stop error 50
Error Code
Error Message
Cause Inspection and Solution
There is nozzle which has
been judged as unavailable
nozzle in LNB in nozzle
changer.
(Single stop error occurred.)
Please change the error nozzle to a
normal nozzle.
44027
Failed in tray position offset
measure.
(Single stop error occurred.)
Please execute tray pickup position1
and pickup position2 action in the
calibration 4th process.
44028
Changer nozzle direction
setting is wrong.
(Single stop error occurred.)
Please set the changer nozzle by
correct direction.
44029
|
44030
Because the F cart isn't
connected or the F moveable
cover is opening^ XY action
can't be executed.
(Interlock occurred.)
Please connect the F cart or close
the F moveable cover.
44031
2-1-3-98
NPM–W2 EJM7DE-MB-02-1T-00
Timer safety relay
abnormal
R moveable cover open or
close action incomplete
error
F moveable cover open or
close action incomplete
error
R cart unconnected error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Because the R cart isn't
connected or the R moveable
cover is opening^ XY action
can't be executed.
(Interlock occurred.)
Please connect the R cart or close
the R moveable cover.
44032
Because the F moveable
cover open or close action is
incomplete^ XY action can't
be executed.
(Interlock occurred.)
Please confirm if the F moveable
cover action is executed correctly in
maintenance screen.
44033
Because the R moveable
cover open or close action is
incomplete^ XY action can't
be executed.
(Interlock occurred.)
Please confirm if the R moveable
cover action is executed correctly in
maintenance screen.
44034
Because the timer safety
relay is time out.
(Interlock occurred.)
Please connect the cart or close the
moveable cover.
44035
2-1-3-99
NPM–W2 EJM7DE-MB-02-1T-00
Cover Open
(Rear Side Safety switch
this side)
Cover Open
(Front Side Safety switch
this side)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
1
Error Code
Error Message
Cause Inspection and Solution
Safety cover is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be at fault.Contact
PFSC.
1302
Safety cover is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the safety cover if opened.
2) If the error persists even after the
safety cover is closed, the safety
switch may be at fault.Contact
PFSC.
1303
2-1-4-1
