NPM–W 2 EJM7DE-MB-02 -1T-00 Support Plate Pos ition Output Error (Right) Support Plate Pos ition Output Error (Left) Changeover C art Unconnected (Rear) Changeover C art Unconnected (Front) Solutions to errors Error Code…
NPM–W2 EJM7DE-MB-02-1T-00
No Feeder cover
(Rear)
No Feeder cover
(Front)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
10
Error Code
Error Message
Cause Inspection and Solution
Feeder cover not attached.
(Interlock occurred.)
Take measures in the following
order.
1) Attach the feeder cover.
2) If the error persists even after the
feeder cover is attached, the
connection with the feeder cover
may not be detected.Choose
[Machine] - [Adjust] - [All] - [Input
confirm] and check the connection
of feeder cover.
1336
Feeder cover not attached.
(Interlock occurred.)
Take measures in the following
order.
1) Attach the feeder cover.
2) If the error persists even after the
feeder cover is attached, the
connection with the feeder cover
may not be detected. Choose
[Machine] - [Adjust] - [All] - [Input
confirm] and check the connection
of the feeder cover.
1337
2-1-4-19
NPM–W2 EJM7DE-MB-02-1T-00
Support Plate Position
Output Error
(Right)
Support Plate Position
Output Error
(Left)
Changeover Cart
Unconnected
(Rear)
Changeover Cart
Unconnected
(Front)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Feeder cart connector not
connected.
(Interlock occurred.)
Connect the feeder cart
again.Choose [Machine] - [Adjust] -
[All] - [Input confirm] and check the
connection of feeder cart. If any
problem is found, contact PFSC.
1339
Feeder cart connector not
connected.
(Interlock occurred.)
Connect the feeder cart
again.Choose [Machine] - [Adjust] -
[All] - [Input confirm] and check the
connection of feeder cart. If any
problem is found, contact PFSC.
1340
Support plate cannot be
raised since the head is
within the mounting area.
(Interlock occurred.)
Move the head away from the
mounting area.
1341
Support plate cannot be
raised since the head is
within the mounting area.
(Interlock occurred.)
Move the head away from the
mounting area.
1342
2-1-4-20
NPM–W2 EJM7DE-MB-02-1T-00
Nozzle Interference Area
Intrusion
(Front Side)
Magazine Door Open
(Rear Tray B)
Magazine Door Open
(Rear Tray A)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
11
Error Code
Error Message
Cause Inspection and Solution
Magazine door is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the magazine door if
opened.
2) If the error persists even after the
magazine door is closed, the
safety switch may be at
fault.Contact PFSC.
1343
Magazine door is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the magazine door if
opened.
2) If the error persists even after the
magazine door is closed, the
safety switch may be at
fault.Contact PFSC.
1344
Any of the following causes
is likely:
1) Z-axis interference sensor
may be at fault or sensor
cable may be broken.
2) Y-axis interference sensor
may be at fault or sensor
cable may be broken.
(Interlock occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and if any problem is
found, contact PFSC.
1349
2-1-4-21
