NPM–W 2 EJM7DE-MB-02 -1T-00 Tape cover detection 2 (Rear) Solutions to errors Error Code Error Message Cause Inspection and Solution Tape cover sensor 2 is blocked. (Interlock occurred.) Take any of the following measure…
NPM–W2 EJM7DE-MB-02-1T-00
Tape cover detection3
(Rear)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
6
Error Code
Error Message
Cause Inspection and Solution
Tape cover sensor 3 is
blocked.
(Interlock occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the top tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 3 of the
table is OFF when the light from
the emitter is blocked and ON
when the light from the emitter
reaches the detector. At this time,
make also sure that the green LED
is lit when the light from the emitter
is blocked and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
1320
2-1-4-11
NPM–W2 EJM7DE-MB-02-1T-00
Tape cover detection2
(Rear)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Tape cover sensor 2 is
blocked.
(Interlock occurred.)
Take any of the following measures:
1) Close the front cover of the tape
feeder.
2) Set the toggle lever of the tape
feeder properly.
3) Make sure that detection area of
the tape cover sensor is not
blocked by the top tape or big
component.
4) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check that the
feeder opening sensor 2 of the
table is OFF when the light from
emitter is blocked and ON when
the light from the emitter reaches
the detector. At this time, make
also sure that the green LED is lit
when the light from the emitter is
blocked and the green and red
LEDs are lit when the light from
the emitter reaches the detector.
1321
2-1-4-12
NPM–W2 EJM7DE-MB-02-1T-00
Support Plate Position
Error
(Right)
Support Plate Position
Error
(Left)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
7
Error Code
Error Message
Cause Inspection and Solution
The support plate has not
lowered completely.
(Interlock occurred.)
Take any of the following measures:
1) Check the grease condition of the
up/down shaft.
2) Remove any foreign body
between the table and machine
base.If the error persists, the
sensor may be displaced or at fault.
Contact PFSC.
1322
The support plate has not
lowered completely.
(Interlock occurred.)
Take any of the following measures:
1) Check the grease condition of the
up/down shaft.
2) Remove any foreign body
between the table and machine
base.If the error persists, the
sensor may be displaced or at fault.
Contact PFSC.
1323
2-1-4-13
