NPM–W2 EJM7DE-MB-02-1T-00
Nozzle Interference Area
Intrusion
(Front Side)
Magazine Door Open
(Rear Tray B)
Magazine Door Open
(Rear Tray A)
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
11
Error Code
Error Message
Cause Inspection and Solution
Magazine door is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the magazine door if
opened.
2) If the error persists even after the
magazine door is closed, the
safety switch may be at
fault.Contact PFSC.
1343
Magazine door is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the magazine door if
opened.
2) If the error persists even after the
magazine door is closed, the
safety switch may be at
fault.Contact PFSC.
1344
Any of the following causes
is likely:
1) Z-axis interference sensor
may be at fault or sensor
cable may be broken.
2) Y-axis interference sensor
may be at fault or sensor
cable may be broken.
(Interlock occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and if any problem is
found, contact PFSC.
1349
2-1-4-21
NPM–W2 EJM7DE-MB-02-1T-00
Magazine Door Open
(Front Tray B)
Magazine Door Open
(Front Tray A)
Nozzle Interference Area
Intrusion
(Rear Side)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Any of the following causes
is likely:
1) Z-axis interference sensor
may be at fault or sensor
cable may be broken.
2) Y-axis interference sensor
may be at fault or sensor
cable may be broken.
(Interlock occurred.)
Choose [Machine] - [Adjust] - [All] -
[Input confirm] and if any problem is
found, contact PFSC.
1350
Magazine door is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the magazine door if
opened.
2) If the error persists even after the
magazine door is closed, the
safety switch may be at
fault.Contact PFSC.
1351
Magazine door is open.
(Interlock occurred.)
Take measures in the following
order.
1) Close the magazine door if
opened.
2) If the error persists even after the
magazine door is closed, the
safety switch may be at
fault.Contact PFSC.
1352
2-1-4-22
NPM–W2 EJM7DE-MB-02-1T-00
Production Data
Abnormality
Software Pointer
Acquisition Error
Software Calculation Error
Software Task
Communication Error
Software Parameter
Abnormality
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
12
Error Code
Error Message
Cause Inspection and Solution
Invalid data set in the
software parameter for X-
axis movement.
(X-axis movement software
parameter error occurred.)
Check the software parameter on
the error window and modify the
production data or machine
parameter if necessary.Contact
PFSC.
1502
Improper procedure was
taken in software processing.
(Software task
communication error
occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1503
Improper procedure was
taken in software processing.
(Software calculation error.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1504
Improper procedure was
taken in software processing.
(Error obtaining software
pointer.)
Check the situation of the error
occurred and error message, and
contact PFSC.
1505
Invalid data set in the
production data.
(Error in production data.)
Check the production data and
correct the data concerned.Contact
PFSC.
1506
2-1-4-23
