NPM–W2 EJM7DE-MB-02-1T-00
Bad Head Retraction
Position Error
Bad Beam Retraction
Position Error
Magazine A Cover Open
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Magazine door is open.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Close the magazine door if
opened.
2) If the error persists, the safety
switch may be broken.
3) Choose [Machine] - [Adjust] - [All]
- [Input confirm] and check the
condition of the magazine door.
40010
Bad X/Y axes are not
positioned at the turnout
position.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Move the X/Y axes to the turnout
position (Front: Y-axis origin
position, rear: Y-axis minus soft
limit position).
2) If the error persists, contact
PFSC.
40011
Bad head not placed at the
turnout position.
(Self-diagnosis error
occurred.)
Move the head to the turnout (Z-axis
origin position).If the error persists,
contact PFSC.
40012
2-1-2-6
NPM–W2 EJM7DE-MB-02-1T-00
Firm version unmatched
error
Vacuum Pump Over Heat
Restart Error Occurred
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 4
Error Code
Error Message
Cause Inspection and Solution
Error occurred in the startup
process.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Restart the machine.
2) If the error persists, contact
PFSC.
40013
Any of the following causes
is likely:
1) Failure of the vacuum
pump
2) Improper setting of
overcurrent protection for
the thermal relay.
(Self-diagnosis error
occurred.)
Reset the thermal relay and choose
[Machine] - [Adjust] - [All] - [Output
confirm] to check the vacuum pump
for proper operation. If any problem
is found, contact PFSC.
40014
Mismatch between the
machine system and
firmware version.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Check the firmware version that
does not match the machine
system on the version information
window.
2) Install the appropriate version for
the system.
40015
2-1-2-7
NPM–W2 EJM7DE-MB-02-1T-00
Air Pressure Error
Momentary Power OFF
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Power supply may have
been stopped momentarily
due to power failure.
(Self-diagnosis error
occurred.)
Check the voltage of the power
supply in the plant. Turn ON the
power and resume production. If the
error persists, contact PFSC.
40016
Abnormal air pressure.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1)Please adjust the regulator when
the supplied air pressure is low.
Please refer to the operating
instruction(Maintenance
articles)about setting pressure.
2)If the air pressure detection
setting(Low limit setting) is too
high, error occurs. Please set the
air pressure detection value to
0.4MPa.
40017
2-1-2-8
