NPM–W2 EJM7DE-MB-02-1T-00
LNB Command Send
Error
PCB Info Confirm Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Failed to check PCB
information during PCB
transfer.
(Error occurred during PCB
information check.)
Take any of the following measures:
1) Check the position of PCB on the
conveyor.
2) Check the setting of
communication between machines.
3) Check the situation of the error
occurred and contact PFSC.
44010
Transmission error occurred
while requesting for reading
external PCB barcode.
(Error occurred in
transferring command to
LNB.)
Take any of the following measures:
1) Check the communication
between the LNB and machine.
2) Check the setting of
communication between machines.
3) Check the situation of the error
occurred and contact PFSC.
44011
2-1-3-93
NPM–W2 EJM7DE-MB-02-1T-00
LNB Command Receive
Timeout
Upper System restriction
Err
Error
Message
Troubleshooting
2-1-3
Single stop error 48
Error Code
Error Message
Cause Inspection and Solution
Reception error occurred
while checking for reading of
external PCB barcode.
(Error occurred in receiving
command from LNB.)
Take any of the following measures:
1) Check the communication
between the LNB and machine.
2) Check the setting of
communication between machines.
3) Check the situation of the error
occurred and contact PFSC.
44012
Timeout occurred while
waiting for reading external
PCB barcode.
(Timeout occurred in receipt
of command from LNB.)
Take any of the following measures:
1) Check the communication
between the LNB and machine.
2) Check the setting of
communication between machines.
3) Check the situation of the error
occurred and contact PFSC.
44013
2-1-3-94
NPM–W2 EJM7DE-MB-02-1T-00
SupportPin descend error
SupportPin rise error
PCB stop pos sensor error
Transfer motor is
abnormal
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Transfer motor driver error
detected during PCB transfer.
(Transfer motor error
occurred.)
Take any of the following measures:
1) Check the transfer motor.
2) Check the condition of the safety
cover and emergency stop switch.
3) Check the situation of the error
occurred and contact PFSC.
44014
Overrun sensor turned ON
prior to PCB stop position
sensor when loading PCBs.
(Error in PCB stop position
sensor error.)
Take any of the following measures:
1) Check the PCB on the conveyor
and condition of the PCB sensor.
2) Check the situation of the error
occurred and contact PFSC.
44015
Failed to raise PCB support.
(Single stop error occurred.)
Check the condition of the upper
limit sensor on the PCB support.
44016
Failed to lower PCB support.
(Single stop error occurred.)
Check the condition of the lower limit
sensor on the PCB support.
44017
2-1-3-95
