NPM–W 2 EJM7DE-MB-02 -1T-00 item name unmatche d LNB Comm. Abnormality All Block NG Judge ment Motor Cooling Fan Alarm Error Message Troubleshooting 2-1-3 Sing le stop er r o r 8 Error Code Error Message Cause Inspection…

100%1 / 338
NPM–W2 EJM7DE-MB-02-1T-00
Main Body Cooling Fan
Alarm
Vacuum pump over heat
Tray Position Recog Error
Serial Calib Value Range
Over
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Mark recognition result for
time-lapse change calibration
has exceeded the setting
value.
(Single stop error occurred.)
Make sure the mark surface at
calibration cylinder is not dirty.
Perform cleaning if found dirty.
40335
Recognition mark is out of
camera's view.
(Single stop error occurred.)
Take measures in the following
order.
1) Move the camera to the
recognition mark position using the
inching function and press the [Re-
recognize] button.
2) If the recognition error occurs
again, move the camera to the
recognition mark position using the
inching function and press the
[Manual set] button.[Manual set]:
Save the inching amount as the
offset.
40336
1) Vacuum pump is at fault.
2) Overcurrent setting for
thermal relay protection has
not been set properly.
(Single stop error occurred.)
Reset the thermal relay. Choose
[Machine] - [Adjust] - [All] - [Output
confirm] and check the vacuum
pump for proper movement. If any
problem is found, contact PFSC.
40337
Cooling fan for the machine
may be at fault or cable may
be broken.
(Single stop error occurred.)
Make sure the cooling fan for the
machine is turning.
40338
2-1-3-13
NPM–W2 EJM7DE-MB-02-1T-00
item name unmatched
LNB Comm. Abnormality
All Block NG Judgement
Motor Cooling Fan Alarm
Error
Message
Troubleshooting
2-1-3
Single stop error 8
Error Code
Error Message
Cause Inspection and Solution
Cooling fan for the Y-axis
motor may be at fault or
cable may be broken.
(Single stop error occurred.)
Make sure the cooling fan for the Y-
axis motor is turning.
40339
All patterns on the PCB were
detected as bad patterns at
bad mark judgement.
(Single stop error occurred.)
Take any of the following measures:
1) Remove the applicable PCB from
the machine and restart production.
2) To pass the PCBs with all bad
patterns, enable the [All pattern
bad board pass].
40340
Communication failed due to
broken cable in the
communication system or
trouble such as power OFF
of the hub.
(Single stop error occurred.)
Check the communication system
and make sure the power to the hub
is turned ON.When simplified LNB
is used, make sure the power to the
PC is turned ON. To restart the LNB
conveyor or simplified LNB PC
during production, set all the
machines on the line to the cycle
stop mode or return to the main
menu to restart production.
40341
Mismatch occurred in the
product name.
(Single stop error occurred.)
Make sure the product name agrees
with that of the previous process.
40342
2-1-3-14
NPM–W2 EJM7DE-MB-02-1T-00
Eject Conv Full Notice
Eject Pallet Full
Eject Pallet Full Notice
Filter Clog Detect
Top Tape Exhaust
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Top tape is broken.
(Single stop error occurred.)
Reset the top tape properly.
40343
Filter clogged.
(Single stop error occurred.)
Clean the filter.
40344
Component eject pallet will
be full soon.
(Single stop error occurred.)
Remove the faulty components from
the component eject pallet.
40345
Component eject pallet is full.
(Single stop error occurred.)
Remove the components in the
component eject pallet.
- When the supply side is provided,
press the [Supply Complete] button.
- If not, choose [Arrange] - [Parts
prepare] - [Tray] - [Arrange] and
press the [Eject Pallet Clear] button.
40346
Component eject conveyor
will be full soon.
(Single stop error occurred.)
Remove NG components from the
eject conveyor.
40347
2-1-3-15
