NPM-W 2 EJM7DE-MB-04T-00 4-2-2 -5 Unit name No. Name Location Remark Independent changeover sup port unit R4514 Movable cover ope n (Right side) Front R4514T Movable cover open (Left side) Front R4515 Movable cover close…
NPM-W2 EJM7DE-MB-04T-00
4-2-2-4
Unit name No. Name
Location Remark
8-nozzle head R3001
Vacuum valve 1
R3002
Vacuum valve 2
R3003
Vacuum valve 3
R3004
Vacuum valve 4
R3005
Vacuum valve 5
R3006
Vacuum valve 6
R3007
Vacuum valve 7
R3008
Vacuum valve 8
R3013
Blow valve 1
R3014
Blow valve 2
R3015
Blow valve 3
R3016
Blow valve 4
R3017
Blow valve 5
R3018
Blow valve 6
R3019
Blow valve 7
R3020
Blow valve 8
3-nozzle head R3001
Vacuum valve 1
R3002
Vacuum valve 2
R3003 Vacuum valve 3
R3013
Blow valve 1
R3014
Blow valve 2
R3015 Blow valve 3
Dispensing head R3001 Air 1
R3002 Air 2
Single tray feeder
main body
R3310
Magazine shutter open
R3311
Replenishment-section shutter close
R3316
Magazine door lock close
R3317
Magazine door lock open
Twin tray feeder main
body
R3310
Magazine shutter open (A)
R3311
Replenishment-section shutter close (A)
R3316
Magazine door lock close (A)
R3317
Magazine door lock open (A)
R3610
Magazine shutter open (B)
R3611
Replenishment-section shutter close (B)
R3616
Magazine door lock close (B)
R3617
Magazine door lock open (B)
Multifunctional transfer
unit
R301 Auto-supply valve
Load arrangement
drawings
NPM-W2 EJM7DE-MB-04T-00
4-2-2-5
Unit name No. Name
Location Remark
Independent
changeover support
unit
R4514 Movable cover open (Right side) Front
R4514T Movable cover open (Left side) Front
R4515 Movable cover close (Right side) Front
R4515T Movable cover close (Left side) Front
R4516 Movable cover open (Right side) Rear
R4516T Movable cover open (Left side) Rear
R4517 Movable cover close (Right side) Rear
R4517T Movable cover close (Left side) Rear
Load lists
Solenoid list 3
Troubleshooting
4-2-2
Option
NPM-W2 EJM7DE-MB-04T-00
Load lists
Sensor list 1
Troubleshooting
4-2-3
4-2-3-1
Standard unit
Unit name No. Name
Location Remark
Main body B1021 Transport window sensor (Right)
B1033 Main air pressure Rear
B1020 Transport window sensor (Left)
B1212 Component-ejection box detection Front
B1222 Component-ejection box detection Rear
B1A04 Y-axis interference detection Front
Feeder table cover
(front)
B1200
Feeder opening sensor 4(Light-receiving section)
Front
B1200T
Feeder opening sensor 4(Light-emitting section)
Front
B1201
Feeder opening sensor 3(Light-receiving section)
Front
B1201T
Feeder opening sensor 3(Light-emitting section)
Front
B1202
Feeder opening sensor 2(Light-receiving section)
Front
B1202T
Feeder opening sensor 2(Light-emitting section)
Front
B1203
Feeder opening sensor 1(Light-receiving section)
Front
B1203T
Feeder opening sensor 1(Light-emitting section)
Front
Feeder table cover
(rear)
(Common to feeder
and tray
specifications)
B1204
Feeder opening sensor 4(Light-receiving section)
Rear
B1204T
Feeder opening sensor 4(Light-emitting section)
Rear
B1205
Feeder opening sensor 3(Light-receiving section)
Rear
B1205T
Feeder opening sensor 3(Light-emitting section)
Rear
B1206
Feeder opening sensor 2(Light-receiving section)
Rear
B1206T
Feeder opening sensor 2(Light-emitting section)
Rear
B1207
Feeder opening sensor 1(Light-receiving section)
Rear
B1207T
Feeder opening sensor 1(Light-emitting section)
Rear
Head option-driving
unit
B01 Cylinder sensor IN Front
B02 Cylinder sensor OUT Front
B03 Option unit identification bit0 Front
B04 Option unit identification bit1 Front
B05 Option unit identification bit2 Front
B06 Option unit identification bit3 Front
B11 Cylinder sensor IN Rear
B12 Cylinder sensor OUT Rear
B13 Option unit identification bit0 Rear
B14 Option unit identification bit1 Rear
B15 Option unit identification bit2 Rear
B16 Option unit identification bit3 Rear
Feeder cart drive unit B1210 Cart unlock (Right) Front
B1210T Cart unlock (Left) Front
B1515T Cart middle check Front *1)
B1216 Cart unlock (Right as seen from the rear side) Rear
B1216T Cart unlock (Left as seen from the rear side) Rear
B1516T Cart middle check Rear *1)
Load arrangement
drawings
*1) Only for independent changeover specifications
