NPM–W 2 EJM7DE-MB-02 -1T-00 3-Nozzle Head PCB Voltage Error Nozzle Wiping Station Setting Error XY Beam Device Error Terma l Regulator 2 Communication Error Solutions to errors Error Code Error Message Cause Inspection a…
NPM–W2 EJM7DE-MB-02-1T-00
Termal Regulator1
Communication Error
Termal Regulator2 Heater
Error
Termal Regulator1 Heater
Error
Termal Regulator2
Thermocouple Error
Termal Regulator1
Thermocouple Error
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 19
Error Code
Error Message
Cause Inspection and Solution
Miswiring^ broken wires or
short-circuit of the
thermocouple in the thermal
regulator
(Self-diagnosis error
occurred.)
Contact PFSC.
40116
Miswiring^ broken wires or
short-circuit of the
thermocouple in the thermal
regulator
(Self-diagnosis error
occurred.)
Contact PFSC.
40117
Broken heater cable or
disconnected heater
thermocouple.
(Self-diagnosis error
occurred.)
Contact PFSC.
40118
Broken heater cable or
disconnected heater
thermocouple.
(Self-diagnosis error
occurred.)
Contact PFSC.
40119
Error occurred in
communication between the
head board and the thermal
regulator board.
(Self-diagnosis error
occurred.)
Contact PFSC.
40120
2-1-2-37
NPM–W2 EJM7DE-MB-02-1T-00
3-Nozzle Head PCB
Voltage Error
Nozzle Wiping Station
Setting Error
XY Beam Device Error
Termal Regulator2
Communication Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Error occurred in
communication between the
head board and the thermal
regulator board.
(Self-diagnosis error
occurred.)
Contact PFSC.
40121
Failed to detect the PNP
information of the X/Y axes
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[PnP] and make sure the X/Y axes
are properly detected, and contact
PFSC.
40122
Any of the following causes
is likely:
1) Nozzle wiping station (for
dispense head only) not set
properly.
2) Component ejection box
has been set.
(Self-diagnosis error
occurred.)
Set the nozzle wiping station
properly.
40123
Voltage at the 3-nozzle
mount head control board
has dropped abnormally.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40124
2-1-2-38
NPM–W2 EJM7DE-MB-02-1T-00
Tray B Control Board Fuse
Disconnection
Tray B Control Board
Temperature Error
Tray B Control Board
Voltage Error
3-Nozzle Head PCB Fuse
Disconnection
3-Nozzle Head PCB
Temperature Error
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 20
Error Code
Error Message
Cause Inspection and Solution
CPU temperature at the 3-
nozzle mount head control
board has exceeded the
setting value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40125
Fuse of the 3-nozzle mount
head control board has
blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40126
Voltage at the tray control
board has dropped
abnormally.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40127
CPU temperature at the tray
control board has exceeded
the setting value.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the temperature, and contact PFSC.
40128
Fuse of the tray control board
has blown.
(Self-diagnosis error
occurred.)
Choose [Machine] - [Information] -
[Firmware] - [Information] to check
the voltage, and contact PFSC.
40129
2-1-2-39
