NPM–W2 EJM7DE-MB-02-1T-00
PCB Carry out Error
PCB Carry in Error
Inside Work Memory Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Internal processing error
occurred during shot
recognition.
(Internal work memory
failure)
Check the situation of the error
occurred and error message, and
contact PFSC.
43524
Timeout occurred while
loading PCB.
(PCB loading error
occurred.)
Take any of the following measures:
1) Check the PCB on the conveyor
and condition of the PCB sensor.
2) Check the conveyor width.
44000
Timeout occurred while
unloading PCB.
(PCB unloading error
occurred.)
Take any of the following measures:
1) Check the PCB on the conveyor
and condition of the PCB sensor.
2) Check the conveyor width.
44001
2-1-3-89
NPM–W2 EJM7DE-MB-02-1T-00
PCB existed Error
Post proc ReqOFF time
out err
Sens err after PCB carry
out
Error
Message
Troubleshooting
2-1-3
Single stop error 46
Error Code
Error Message
Cause Inspection and Solution
Stop position sensor was ON
after unloading PCB.
(Error occurred in sensor
after unloading PCB.)
Take any of the following measures:
1) Check the PCB on the conveyor
and condition of the PCB sensor.
2) Check the conveyor width.
44002
PCB request signal from
next process machine after
unloading PCB failed to turn
OFF within the prescribed
time.
(Timeout error occurred
while waiting for request
OFF from next process
machine.)
Take any of the following measures:
1) Check the PCB on the conveyor
and condition of the PCB sensor.
2) Check the setting value of PCB
eject waiting time (request OFF).
44003
PCB stop position sensor
was ON before loading PCB.
(PCB presence detected
when loading PCB.)
Check the PCB on the conveyor and
condition of the PCB sensor.
44004
2-1-3-90
NPM–W2 EJM7DE-MB-02-1T-00
Middle Request ON time
out
PCB Motion Error
Conv over run sensor
abnormally
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Sensor did not turn ON in
back movement due to
overrun detection when
loading PCB.
(Error occurred in overrun
sensor when loading PCB.)
Check the PCB on the conveyor and
condition of the PCB sensor.
44005
Stop position sensor turned
OFF in back movement due
to overrun detection when
loading PCB.
(PCB positioning error
occurred when loading
PCB.)
Check the PCB on the conveyor and
condition of the PCB sensor.
44006
PCB request signal from
next process machine failed
to turn ON during middle
standby transfer between
machines.
(Timeout error occurred
during middle standby
transfer between machines.)
Take any of the following measures:
1) Check the status of
synchronization and middle
standby confirmation signals
between the machines.
2) Check the situation of the error
occurred and contact PFSC.
44007
2-1-3-91
