NPM-W 2 EJM7DE-MB-04T-00 4-2-2 -1 Load lists Solenoid list 1 Troubleshooting 4-2-2 Unit name No. Name Location Remark Main body R4200 T ruck lock Front R4201 T ruck unlock Front R4202 T ape cutter 1 Front R4203 T ape cut…
NPM-W2 EJM7DE-MB-04T-00
Unit name No. Name
Location Remark
8-nozzle head M401
-axis motor 1
M402
-axis motor 2
M403
Z-axis motor 1
M404
Z-axis motor 2
M405
Z-axis motor 3
M406
Z-axis motor 4
M407
Z-axis motor 5
M408
Z-axis motor 6
M409
Z-axis motor 7
M410
Z-axis motor 8
G1001
CPU cooling fan motor
3-nozzle head M401
-axis motor 1
M402
-axis motor 2
M405
-axis motor 3
M403
Z-axis motor 1
M404
Z-axis motor 2
M406 Z-axis motor 3
G1001
CPU cooling fan motor
Dispensing head M401
-axis motor 1
M402
-axis motor 2
M403
Z-axis motor 1
M404
Z-axis motor 2
M405
SC-axis motor 1
M406
SC-axis motor 2
G1001
Cooling fan motor 1
G1002
Cooling fan motor 2
Single tray feeder
main body
G101 Cooling fan motor
Single tray feeder
lifter
M401 TL-axis motor
Single tray feeder
drawer
M402 TP-axis motor
Multifunctional
transfer unit
M401 TS motor
M402 TY motor
Twin tray feeder main
body
G101 Cooling fan motor (A)
G102 Cooling fan motor (B)
Twin tray feeder lifter M401 TL-axis motor (A)
M403 TL-axis motor (B)
Twin tray feeder
drawer
M402 TP-axis motor (A)
M404 TP-axis motor (B)
4-2-1-4
Load arrangement
drawings
NPM-W2 EJM7DE-MB-04T-00
4-2-2-1
Load lists
Solenoid list 1
Troubleshooting
4-2-2
Unit name No. Name
Location Remark
Main body R4200 Truck lock Front
R4201 Truck unlock Front
R4202 Tape cutter 1 Front
R4203 Tape cutter 2 Front
R4210 Truck lock Rear
R4211 Truck unlock Rear
R4212 Tape cutter 1 Rear
R4213 Tape cutter 2 Rear
R4230 Blow pressure change valve (Front) Front
R4234 Blow pressure change valve (Rear) Front
R5001 Main air valve Rear
Head option-driving
unit
R01 Valve Open Front
R11 Valve Close Rear
PCB holder
(single conveyor)
R4130 PCB support change Ascent (Placement position
right)
R4131 PCB support change Descent (Placement position
right)
R4132 PCB support change Ascent (Placement position
left)
R4133 PCB support change Descent (Placement position
left)
R4134 PCB support Ascent (Placement position right)
R4135 PCB support Descent (Placement position right)
R4222 PCB support plate up-down speed switch
(Placement position right)
R4136 PCB support Ascent (Placement position left)
R4137 PCB support Descent (Placement position left)
R4223 PCB support plate up-down speed switch 2
PCB holder
(dual conveyor)
R4134 PCB support Ascent (Lane 1 right)
R4135 PCB support Descent (Lane 1 right)
R4222 PCB support plate up-down speed switch (Lane 1
right)
R4136 PCB support Ascent (Lane 1 left)
R4137 PCB support Descent (Lane 1 left)
R4223 PCB support plate up-down speed switch (Lane 1
left)
R4503 PCB support Ascent (Lane 2 right)
R4513 PCB support Descent (Lane 2 right)
R4526 PCB support plate up-down speed switch (Lane 2
right)
R4504 PCB support Ascent (Lane 2 left)
R4505 PCB support Descent (Lane 2 left)
R4531 PCB support plate up-down speed switch (Lane 2
left)
Standard unit
NPM-W2 EJM7DE-MB-04T-00
4-2-2-2
Unit name No. Name
Location Remark
16-nozzle head R3001 Vacuum valve 1
R3002 Vacuum valve 2
R3003 Vacuum valve 3
R3004 Vacuum valve 4
R3005 Vacuum valve 5
R3006 Vacuum valve 6
R3007 Vacuum valve 7
R3008 Vacuum valve 8
R3009 Vacuum valve 9
R3010 Vacuum valve 10
R3011 Vacuum valve 11
R3012 Vacuum valve 12
R3013 Vacuum valve 13
R3014 Vacuum valve 14
R3015 Vacuum valve 15
R3016 Vacuum valve 16
R3021 Blow valve 1
R3022 Blow valve 2
R3023 Blow valve 3
R3024 Blow valve 4
R3035 Blow valve 5
R3026 Blow valve 6
R3027 Blow valve 7
R3928 Blow valve 8
R3029 Blow valve 9
R3030 Blow valve 10
R3031 Blow valve 11
R3032 Blow valve 12
R3033 Blow valve 13
R4034 Blow valve 14
R3035 Blow valve 15
R3036 Blow valve 16
Option
Load arrangement
drawings
