NPM–W 2 EJM7DE-MB-02 -1T-00 Eject Conv Full Notice Eject Pallet Full Eject Pallet Full Notice Filter Clog Detect Top Tape Exhaust Solutions to errors Error Code Error Message Cause Inspection and Solution Top tape is bro…

NPM–W2 EJM7DE-MB-02-1T-00

item name unmatched

LNB Comm. Abnormality

All Block NG Judgement

Motor Cooling Fan Alarm

Error

Message

Troubleshooting

2-1-3

Single stop error 8

Error Code

Error Message

Cause Inspection and Solution

Cooling fan for the Y-axis

motor may be at fault or

cable may be broken.

(Single stop error occurred.)

Make sure the cooling fan for the Y-

axis motor is turning.

40339

All patterns on the PCB were

detected as bad patterns at

bad mark judgement.

(Single stop error occurred.)

Take any of the following measures:

1) Remove the applicable PCB from

the machine and restart production.

2) To pass the PCBs with all bad

patterns, enable the [All pattern

bad board pass].

40340

Communication failed due to

broken cable in the

communication system or

trouble such as power OFF

of the hub.

(Single stop error occurred.)

Check the communication system

and make sure the power to the hub

is turned ON.When simplified LNB

is used, make sure the power to the

PC is turned ON. To restart the LNB

conveyor or simplified LNB PC

during production, set all the

machines on the line to the cycle

stop mode or return to the main

menu to restart production.

40341

Mismatch occurred in the

product name.

(Single stop error occurred.)

Make sure the product name agrees

with that of the previous process.

40342

2-1-3-14

NPM–W2 EJM7DE-MB-02-1T-00

Eject Conv Full Notice

Eject Pallet Full

Eject Pallet Full Notice

Filter Clog Detect

Top Tape Exhaust

Solutions to errors

Error Code

Error Message

Cause Inspection and Solution

Top tape is broken.

(Single stop error occurred.)

Reset the top tape properly.

40343

Filter clogged.

(Single stop error occurred.)

Clean the filter.

40344

Component eject pallet will

be full soon.

(Single stop error occurred.)

Remove the faulty components from

the component eject pallet.

40345

Component eject pallet is full.

(Single stop error occurred.)

Remove the components in the

component eject pallet.

- When the supply side is provided,

press the [Supply Complete] button.

- If not, choose [Arrange] - [Parts

prepare] - [Tray] - [Arrange] and

press the [Eject Pallet Clear] button.

40346

Component eject conveyor

will be full soon.

(Single stop error occurred.)

Remove NG components from the

eject conveyor.

40347

2-1-3-15

NPM–W2 EJM7DE-MB-02-1T-00

Power Box Heat Anomaly

CPU Box Heat Anomaly

Eject Conv Full

Error

Message

Troubleshooting

2-1-3

Single stop error 9

Error Code

Error Message

Cause Inspection and Solution

Component eject conveyor is

full.

(Single stop error occurred.)

Remove NG components from the

eject conveyor.

40348

Temperature in the CPU box

is high.

(Single stop error occurred.)

Make sure the cooling fan in the

bottom left of the box is turning.

40349

Cooling fan is at fault.

(Single stop error occurred.)

Take any of the following measures:

1) Make sure the cooling fan at left

side of bottom of the machine is

turning.

2) Choose [Machine] - [Adjust] - [All]

- [Input confirm] and check the

power box for proper

temperature.ON :NormalOFF:Hot

(abnormal)

3) Wait until the power box is cooled

down and restart the machine.

40350

2-1-3-16
