NPM–W 2 EJM7DE-MB-02 -1T-00 Air Pressure Error Momentary Power OFF Solutions to errors Error Code Error Message Cause Inspection and Solution Power su pply may h ave been stopped moment arily due to power failure. (Self-…

100%1 / 338
NPM–W2 EJM7DE-MB-02-1T-00
Firm version unmatched
error
Vacuum Pump Over Heat
Restart Error Occurred
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 4
Error Code
Error Message
Cause Inspection and Solution
Error occurred in the startup
process.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Restart the machine.
2) If the error persists, contact
PFSC.
40013
Any of the following causes
is likely:
1) Failure of the vacuum
pump
2) Improper setting of
overcurrent protection for
the thermal relay.
(Self-diagnosis error
occurred.)
Reset the thermal relay and choose
[Machine] - [Adjust] - [All] - [Output
confirm] to check the vacuum pump
for proper operation. If any problem
is found, contact PFSC.
40014
Mismatch between the
machine system and
firmware version.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Check the firmware version that
does not match the machine
system on the version information
window.
2) Install the appropriate version for
the system.
40015
2-1-2-7
NPM–W2 EJM7DE-MB-02-1T-00
Air Pressure Error
Momentary Power OFF
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Power supply may have
been stopped momentarily
due to power failure.
(Self-diagnosis error
occurred.)
Check the voltage of the power
supply in the plant. Turn ON the
power and resume production. If the
error persists, contact PFSC.
40016
Abnormal air pressure.
(Self-diagnosis error
occurred.)
Take any of the following measures:
1)Please adjust the regulator when
the supplied air pressure is low.
Please refer to the operating
instruction(Maintenance
articles)about setting pressure.
2)If the air pressure detection
setting(Low limit setting) is too
high, error occurs. Please set the
air pressure detection value to
0.4MPa.
40017
2-1-2-8
NPM–W2 EJM7DE-MB-02-1T-00
No Priming shot unit
No Changer unit
Error
Message
Troubleshooting
2-1-2
Self-diagnosis errors 5
Error Code
Error Message
Cause Inspection and Solution
Nozzle changer not installed.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Install the unit corresponding to
the head.
2) If the error persists even after the
unit is installed, the connection
with the unit may not be
detected.Choose [Machine] -
[Adjust] - [All] - [Input confirm] and
check the connection of units.
40018
Priming shot unit not
installed.
(Self-diagnosis error
occurred.)
Take measures in the following
order.
1) Install the unit corresponding to
the head.
2) If the error persists even after the
unit is installed, the connection
with the unit may not be
detected.Choose [Machine] -
[Adjust] - [All] - [Input confirm] and
check the connection of units.
40019
2-1-2-9
