NPM-W2 EJM7DE-MB-04T-00
Load lists
Sensor list 1
Troubleshooting
4-2-3
4-2-3-1
Standard unit
Unit name No. Name
Location Remark
Main body B1021 Transport window sensor (Right)
B1033 Main air pressure Rear
B1020 Transport window sensor (Left)
B1212 Component-ejection box detection Front
B1222 Component-ejection box detection Rear
B1A04 Y-axis interference detection Front
Feeder table cover
(front)
B1200
Feeder opening sensor 4(Light-receiving section)
Front
B1200T
Feeder opening sensor 4(Light-emitting section)
Front
B1201
Feeder opening sensor 3(Light-receiving section)
Front
B1201T
Feeder opening sensor 3(Light-emitting section)
Front
B1202
Feeder opening sensor 2(Light-receiving section)
Front
B1202T
Feeder opening sensor 2(Light-emitting section)
Front
B1203
Feeder opening sensor 1(Light-receiving section)
Front
B1203T
Feeder opening sensor 1(Light-emitting section)
Front
Feeder table cover
(rear)
(Common to feeder
and tray
specifications)
B1204
Feeder opening sensor 4(Light-receiving section)
Rear
B1204T
Feeder opening sensor 4(Light-emitting section)
Rear
B1205
Feeder opening sensor 3(Light-receiving section)
Rear
B1205T
Feeder opening sensor 3(Light-emitting section)
Rear
B1206
Feeder opening sensor 2(Light-receiving section)
Rear
B1206T
Feeder opening sensor 2(Light-emitting section)
Rear
B1207
Feeder opening sensor 1(Light-receiving section)
Rear
B1207T
Feeder opening sensor 1(Light-emitting section)
Rear
Head option-driving
unit
B01 Cylinder sensor IN Front
B02 Cylinder sensor OUT Front
B03 Option unit identification bit0 Front
B04 Option unit identification bit1 Front
B05 Option unit identification bit2 Front
B06 Option unit identification bit3 Front
B11 Cylinder sensor IN Rear
B12 Cylinder sensor OUT Rear
B13 Option unit identification bit0 Rear
B14 Option unit identification bit1 Rear
B15 Option unit identification bit2 Rear
B16 Option unit identification bit3 Rear
Feeder cart drive unit B1210 Cart unlock (Right) Front
B1210T Cart unlock (Left) Front
B1515T Cart middle check Front *1)
B1216 Cart unlock (Right as seen from the rear side) Rear
B1216T Cart unlock (Left as seen from the rear side) Rear
B1516T Cart middle check Rear *1)
Load arrangement
drawings
*1) Only for independent changeover specifications
NPM-W2 EJM7DE-MB-04T-00
4-2-3-2
Unit name No. Name
Location Remark
Single conveyor
B1127
Lane 1 Left waiting PCB detection 1
B1131
Lane 1 Left waiting PCB detection 2
B1136
Lane 1 Placement position PCB detection 1
B1113
Lane 1 Placement position PCB detection 2
B1012
Lane 1 Placement position PCB detection 6
B1123
Lane 1 Placement position PCB detection 3
B1122
Lane 1 Placement position PCB detection 4
B1115
Lane 1 Placement position PCB detection 5
B1121
Lane 1 Right waiting PCB detection 1
B1120
Lane 1 Right waiting PCB detection 2
B1C00 Lane 1 Width adjustment axis (Origin detection)
B1C01 Lane 1 Support pin detection
B1C02
Lane 1 Origin of width adjustment axis in Single
lane mode
PCB holder
(single conveyor)
B1140
PCB support change interlock
(placement position right)
B1141
PCB support change interlock
(placement position left)
B1233
PCB support change lower-limit (placement
position right)
B1234
PCB support change lower-limit (placement
position left)
B1235
PCB support plate upper limit (placement position left)
B1236
PCB support plate lower limit (placement position left)
B1244
PCB support plate upper limit (placement position right)
B1245
PCB support plate lower limit (placement position right)
Dual conveyor
B1127
Lane 1 Left waiting PCB detection 1
B1131
Lane 1 Left waiting PCB detection 2
B1136
Lane 1 Placement position PCB detection 1
B1113
Lane 1 Placement position PCB detection 2
B1012
Lane 1 Placement position PCB detection 6
B1123
Lane 1 Placement position PCB detection 3
B1122
Lane 1 Placement position PCB detection 4
B1115
Lane 1 Placement position PCB detection 5
B1121
Lane 1 Right waiting PCB detection 1
B1120
Lane 1 Right waiting PCB detection 2
B1C00 Lane 1 Width adjustment axis (Origin detection)
B1C01 Lane 1 Support pin detection
B1C02
Lane 1 Origin of width adjustment axis in Single
lane mode
Load lists
Sensor list 2
Troubleshooting
4-2-3
Option
NPM-W2 EJM7DE-MB-04T-00
4-2-3-3
Unit name No. Name
Location Remark
Dual conveyor
B1133
Lane 2 Left waiting PCB detection 1
B1132
Lane 2 Left waiting PCB detection 2
B1134
Lane 2 Placement position PCB detection 1
B1112
Lane 2 Placement position PCB detection 2
B1107
Lane 2 Placement position PCB detection 6
B1125
Lane 2 Placement position PCB detection 3
B1124
Lane 2 Placement position PCB detection 4
B1117
Lane 2 Placement position PCB detection 5
B1126
Lane 2 Right waiting PCB detection 1
B1130
Lane 2 Right waiting PCB detection 2
B1D00
Lane 2 Origin of width adjustment axis in
single lane mode
B1D01 Lane 2 Support pin detection
B1C03 Single lane mode detection
PCB holder
(dual conveyor)
B1244
Lane 1 PCB support upper limit (placement
position right)
B1245
Lane 1 PCB support lower limit (placement
position right)
B1235
Lane 1 PCB support upper limit (placement
position left)
B1236
Lane 1 PCB support lower limit (placement
position left)
B1533
Lane 2 PCB support upper limit (placement
position right)
B1534
Lane 2 PCB support lower limit (placement
position right)
B1540
Lane 2 PCB support upper limit (placement
position left)
B1541
Lane 2 PCB support lower limit (placement
position left)
Light weight 16-nozzle
head
B1001 Flow sensor 1
B1002 Flow sensor 2
B1003 Flow sensor 3
B1004 Flow sensor 4
B1005 Flow sensor 5
B1006 Flow sensor 6
B1007 Flow sensor 7
B1008 Flow sensor 8
B1009 Flow sensor 9
B1010
Flow sensor 10
B1011 Flow sensor 11
B1012 Flow sensor 12
B1013 Flow sensor 13
B1014 Flow sensor 14
B1015 Flow sensor 15
B1016 Flow sensor 16
Load arrangement
drawings
