NPM–W2 EJM7DE-MB-02-1T-00
Origin Return Unexecuted
Axis Stroke Sensor
Detection
Wiring Error
SP Axis Cover Open
Head Collision Range
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
SP-axis (shuttle pick-up) is in
the interlock area above the
pallet^ which has caused
interlock for the TL-axis to
stop it.
(Head interference area error
occurred.)
Make sure there is nothing wrong
with the head for moving the SP-
axis and move the head near to the
origin, then restart the machine.
2169
SP-axis cover opened while
the shuttle was moving.
(SP-axis cover open error
occurred.)
Close the SP-axis cover.
2170
Wiring communication failed.
(Wiring error occurred.)
Check the situation of the error
occurred and error message, and
contact PFSC.
2171
Error was detected by the
axis stroke sensor.
(Axis stroke sensor error
occurred.)
Return the axis to its origin again. If
the error persists, check the axis
stroke sensor.
2172
Movement command was
issued without performing
origin return.
(Origin return unexecuted
error occurred.)
Perform origin return.
2174
2-1-4-104
NPM–W2 EJM7DE-MB-02-1T-00
Tray Counter Abnormality
Pick-up Section Pallet
Number Setting Error
Supply Section Pallet
Number Setting Error
Speed Number Out of
Range
Command Issue in
Executing
Error
Message
Troubleshooting
2-1-4
Emergency stop errors
53
Error Code
Error Message
Cause Inspection and Solution
Another movement
command was issued while a
movement command was
being executed.
(Command issue error
occurred during execution.)
Check the situation of the error
occurred and error message, and
contact PFSC.
2175
Moving speed of the tray
data is abnormal.
(Speed No. out of range
error occurred.)
Make sure there is nothing wrong
with the tray data.If the error
persists, check the situation of the
error occurred and error message,
and contact PFSC.
2176
Invalid pallet number.
(Feeder pallet No. setting
error occurred.)
Set the pallet number of the feeder
carriage on the pallet position check
screen.
2177
Invalid pallet number.
(Pickup pallet No. setting
error occurred.)
Set the pallet number of the feeder
carriage on the pallet position check
screen.
2178
Invalid value set in the tray
counter.
(Tray counter error occurred.)
Set a proper tray counter value on
the tray arrangement screen.
2179
2-1-4-105
NPM–W2 EJM7DE-MB-02-1T-00
Undefined Axis Operation
Status Setting
Undefined Shutter Setting
Undefined Axis Setting
Supply Finish Monitor
Abnormality
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Error occurred in the Supply
Complete switch monitoring
processing of the tray feeder.
(Supply completion monitor
error occurred.)
Close the error screen and restart
production.If the error persists,
check the situation of the error
occurred and error message, and
contact PFSC.
2180
Wrong axis command was
issued to the tray.
(Undefined axis error
occurred.)
Close the error screen and restart
production.If the error persists,
check the situation of the error
occurred and error message, and
contact PFSC.
2181
Undefined shutter motion
command to the tray was
issued.
(Undefined shutter
designation error occurred.)
Close the error screen and restart
production.If the error persists,
check the situation of the error
occurred and error message, and
contact PFSC.
2182
Axis error occurred but the
cause cannot be identified.
(Undefined axis motion
designation error occurred.)
Close the error screen and restart
production.If the error persists,
check the situation of the error
occurred and error message, and
contact PFSC.
2183
2-1-4-106
