NPM–W2 EJM7DE-MB-02-1T-00
Parts Recognition Error
Parts Recognition Error
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
Component height measured
through multi recognition
camera is invalid.
(Recognition error
Component height
recognition anomaly)
1)Please confirm if each parameter
of component data is set correctly.
2)Please confirm if there is any
abnormality in component.
3)Please confirm the thick offset
maximum value/minimum value
when the thick measure is
selected to [ON].
4)Please execute the following
setting because the component
can't be height measured.Select
the 2D camera.Set the [Lead comp
reverse] option to OFF.Set the
thick measure to [OFF].
43048
Bad mark was judged to be
present in bad mark
recognition.
(Recognition error -
Detection error in target
marks for judgment)
If this error occurs at the position
with no bad marks during bad mark
recognition, check the mark
judgment area size, setting lamp
value and image TH value.Presence
of mark cannot be determined
reliably when using an unstable
location in the image.Perform
teaching so that there may be
difference in image stable enough to
determine the presence of mark.
43049
2-1-3-81
NPM–W2 EJM7DE-MB-02-1T-00
Rough Detect Error
(0)
Picture contrast Error
Error
Message
Troubleshooting
2-1-3
Single stop error 42
Error Code
Error Message
Cause Inspection and Solution
Failed to find threshold for
boundary detection.
(Insufficient dispensing error
occurred during priming shot
recognition.)
Take any of the following measures:
1) Execute eject check by
dispensing the material forcibly.
2) Perform priming shot teaching
and check the shot condition.
3) Correct the parameter(s) that
caused the error.
43501
No pattern detected during
boundary detection.
(Insufficient dispensing error
occurred during priming shot
recognition.)
Take any of the following measures:
1) Execute eject check by
dispensing the material forcibly.
2) Perform priming shot teaching
and check the shot condition.
3) Correct the parameter(s) that
caused the error.
43502
2-1-3-82
NPM–W2 EJM7DE-MB-02-1T-00
Nozzle Stuffed Check
Error
Rough Detect Error
(1)
Solutions to errors
Error Code
Error Message
Cause Inspection and Solution
No pattern detected after
removing noise or skipped
pattern.
(Insufficient dispensing error
occurred during priming shot
recognition.)
Take any of the following measures:
1) Execute eject check by
dispensing the material forcibly.
2) Perform priming shot teaching
and check the shot condition.
3) Correct the parameter(s) that
caused the error.
43503
No pattern found in more
than one point of multiple
nozzles in clogged nozzle
check.
(Clogged nozzle error
occurred during priming shot
recognition.)
Take any of the following measures:
1) Execute eject check by
dispensing the material forcibly.
2) Check the nozzle in use.
3) Perform priming shot teaching
and check the shot condition.
4) Correct the parameter(s) that
caused the error.
43504
2-1-3-83
